| Application |
C A T excavator engine parts |
| Name |
EGR Tube |
| Parts No |
3940123 394-0123 |
| Model |
CT15
|
| Delivery time |
Stock for urgent delivery |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Design |
made in china |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT Express |
| Packing |
As request or standard packing |
TRUCK ENGINE CT15
- More tube parts supplied to C A T machine
| 3940104 TUBE-INTERCOOLER |
| Caterpillar |
| |
| 3940077 TUBE AS-ISC COOL |
| Caterpillar |
| |
| 3940076 TUBE AS-CCV |
| Caterpillar |
| |
| 3940072 TUBE AS-CCV |
| Caterpillar |
| |
| 3940067 TUBE AS-EGR COOL |
| Caterpillar |
| |
| 3940066 TUBE AS-EGR COOL |
| Caterpillar |
| |
| 3990512 TUBE-EGR COOLANT |
| Caterpillar |
| |
| 3975147 TUBE-WATER |
| Caterpillar |
| |
| 3975144 TUBE |
| Caterpillar |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
|
|
For all Parts Technical inquiries, please contact the On-Highway Product Support at 1-800-338-3428 |
| 1 |
394-0126 |
[1] |
SUPPORT-EGR CLR SUPPORT EGR COOLER |
|
| 2 |
394-0129 |
[1] |
SUPPORT-EGR CLR SUPPORT EGR COOLER |
|
| 3 |
376-2495 |
[6] |
BOLT-HEX FLNG BOLT M8 X 35-10.9 HEX FLG |
|
| 4 |
379-1219 |
[7] |
WASHER-LOCK HDN WASHER FLAT .406X.812X.089 PHC |
|
| 5 |
393-9737 |
[5] |
BOLT BOLT 3/8 X 2-1/2 PHC TYPE 8 |
|
| 6 |
394-0141 |
[1] |
COOLER AS-EGR COOLER ASM, EGR |
|
| 6 |
|
|
BEFORE 09/13/2012 (Reference) BEFORE 09/13/2012 |
| 6 |
394-0141 |
[1] |
COOLER AS-EGR COOLER, ASM EGR |
|
| 6 |
|
|
09/13/2012 AND LATER (Reference) 09/13/2012 AND LATER |
| 7 |
376-2720 |
[6] |
BOLT-HEX FLANGE BOLT HEX FLANGE M8 X 45 B16 |
|
| 8 |
376-2513 |
[5] |
BOLT-HEX FLNG BOLT M10 X 45MM HEX FLANGE |
|
| 9 |
394-0058 |
[1] |
STUD-BOLT STUD BOLT M10X45 |
|
| 10 |
393-9755 |
[3] |
GASKET-EGR GASKET EGR |
|
| 11 |
393-9944 G |
[1] |
VALVE AS-EGR VALVE ASM EGR |
|
| 12 |
394-0123 |
[1] |
TUBE-EGR CLR TUBE EGR COOLER SUPPLY |
|
| 13 |
393-9956 |
[4] |
BOLT-HIGH TEMP BOLT HIGH TEMP M10 X 130 |
|
| 14 |
394-0124 |
[1] |
ELBOW-EGR INLET ELBOW EGR COOLER INLET |
|
| 15 |
398-7753 |
[3] |
BOLT BOLT M10X1.5X40MM |
|
| 16 |
394-0112 |
[1] |
SUPPORT-EGR CLR SUPPORT EGR COOLER |
|
| 17 |
394-0113 |
[1] |
SUPPORT-EGR CLR SUPPORT EGR COOLER |
|
| 18 |
376-2500 |
[1] |
BOLT-HEX FLNG BOLT, M10X30 HEX FLANGE |
|
| 19 |
376-2537 |
[2] |
BOLT-STUD BOLT STUD M10 X 20 X 35 |
|
| 20 |
393-9727 |
[4] |
BOLT-HEX FLANGE BOLT HEX FLG HD-M8 X 27 |
|
| 21 |
394-0130 |
[1] |
GUIDE-EGR COOL GUIDE EGR COOLANT DRAIN |
|
| 22 |
393-9706 |
[1] |
BOLT-HEX FLANGE BOLT M6 X 1.25 12MM HEX FLANGE |
|
| 23 |
393-9758 |
[1] |
GASKET-THROTTLE GASKET THROTTLE BODY |
|
| 24 |
G |
[1] |
VALVE AS-THRT VALVE ASM INTAKE THROTTLE |
| 25 |
393-9740 |
[4] |
BOLT BOLT 3/8 X 3-1/2 PHC TYPE 8 |
|
| 26 |
393-9728 |
[1] |
GASKET-EXHAUST GASKET EXHAUST SINGLE LAYER |
|
| 27 |
360-0920 |
[2] |
BOLT-HEX HD BOLT HH 5/16X1 PHC TYP 8 |
|
| 28 |
376-2490 |
[3] |
BOLT-CRANKCASE BOLT CRANKCASE M8X30-10.9 HF |
|
| 29 |
398-7802 |
[1] |
EXTENSION-CLIP EXTENSION CLIP |
|
| 30 |
|
[4] |
NUT M8 - HF LOCK |
| 31 |
394-0064 |
[2] |
BOLT AS-W/LINER BOLT ASM U M8 W/LINER |
|
| 32 |
393-9964 |
[1] |
HOSE-EGR SUPPLY HOSE, EGR SUPPLY |
|
| 32 |
393-9964 |
[1] |
HOSE-EGR SUPPLY HOSE EGR SUPPLY |
|
| 33 |
393-9759 |
[2] |
CLAMP-EGR CLAMP EGR |
|
| 34 |
398-7805 |
[1] |
PIPE-AIR CASTING PIPE AIR CASTING |
|
| 35 |
379-1469 |
[1] |
RING-O, RING O |
|
| 36 |
379-1457 |
[1] |
CLAMP-PIPE CLAMP PIPE |
|
| 37 |
393-9954 |
[1] |
TUBE-EGR TUBE EGR CROSSOVER |
|
| 38 |
394-0065 |
[1] |
SUPPORT AS-EGR SUPPORT ASM EGR TUBE |
|
| 800 |
|
|
NOTE: THE FOLLOWING PARTS ARE NON-ILLUSTRATED (Reference) NOTE: THE FOLLOWING PARTS ARE NON-ILLUSTRATED |
| 801 |
380-2854 |
[2] |
WASHER-LOCK HDN WASHER FLAT .344X.688X.089 PHC |
|
| 870 |
399-0162 |
|
KIT-TUBE GASKETS (Kit) KIT COLDSIDE TUBE GASKETS |
|
| 870 |
|
|
(CONSISTS OF PARTS DENOTED BY A) (Reference) (CONSISTS OF PARTS DENOTED BY A) |
| 871 |
|
|
KIT-GASKET&BOLTS (Kit) KIT HOTSIDE GASKETS & BOLTS |
| 871 |
|
|
(CONSISTS OF PARTS DENOTED BY B) (Reference) (CONSISTS OF PARTS DENOTED BY B) |
| 872 |
399-0163 |
|
KIT-EGR TUBE (Kit) KIT EGR COLDSIDE TUBE & GASKET |
|
| 872 |
|
|
(CONSISTS OF PARTS DENOTED BY C) (Reference) (CONSISTS OF PARTS DENOTED BY C) |
| 873 |
399-0153 |
|
KIT-A INTK DUCT (Kit) KIT THROTTLE VALVE |
|
| 873 |
|
|
(CONSISTS OF PARTS DENOTED BY D) (Reference) (CONSISTS OF PARTS DENOTED BY D) |
| 874 |
399-0171 |
|
KIT-EGR VALVE (Kit) KIT, EGR VALVE |
|
| 874 |
|
|
(CONSISTS OF PARTS DENOTED BY E) (Reference) (CONSISTS OF PARTS DENOTED BY E) |
| 875 |
399-0153 |
|
KIT-A INTK DUCT (Kit) KIT, AIR INTAKE THROTTLE DUCT |
|
| 875 |
|
|
(CONSISTS OF PARTS DENOTED BY F) (Reference) (CONSISTS OF PARTS DENOTED BY F) |
| 880 |
|
|
NOTE: ASM BELOW COMPRISED OF ABOVE COMPONENTS (Reference) NOTE: ASM BELOW COMPRISED OF ABOVE COMPONENTS |
| 881 |
A |
|
EGR SYSTEM (Reference) EGR SYSTEM |
| |
A |
|
Contact 800-338-3428/onhighwaysupport@cat.com |
| |
G |
|
Not Serviced - Order Kit |
| |
|
|
|
|
