Product Details:
Payment & Shipping Terms:
|
| Category: | Fuel System | Machine Model: | HX220L HX235L HX260L HX300L HX330L HX380L HX430L |
|---|---|---|---|
| Application: | F-Series Crawler Excavator | Product Name: | Fuel Filter |
| Part Number: | 11KA71040 11QA71040 | Packing: | Standard Export Carton |
| Highlight: | HX220L Fuel Filter,11KA71040 Fuel Filter,11QA71040 Fuel Filter |
||
| Name | Fuel Filter |
| Parts No | 11KA71040 11QA71040 |
| Machine Model | HX220L HX235L HX260L HX300L HX330L HX380L HX430L |
| Category | Fuel System |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT EMS |
| Packing | As request or standard packing |
| 31E3-0018 ELEMENT-LINE FILTER |
| 100D-7, 110D-7A, 110D-7E, 110D-9, 110DE, 33HDLL, 42HDLL, 50D-7A, 50D-7K, 50D-9, 50DE, 50DEACE, 80D-9, 80DE, 80DEACE, HL25C, HL35C, HL720-3, HL720-3C, HL730-7, HL730-9S, HL730-9SB, HL7303, HL7303C, HL7... |
| 31EE-02110 ELEMENT |
| 15D, 15D-9, 15D-9S, 15G-7M, 15L-7M, 15LC-7M, 20D-7E, 20DF, 20DT, 22D-9, 22D-9E, 22D-9T, 25G-7M, 25GC-7A, 25GC-7M, 25GC-7S, 25L-7A, 25L-7M, 25LC-7A, 25LC-7M, 25LC-7S, 25LF, 35D-9, 35D-9K, 35D-9S, 50D-9... |
| 11N6-27030 ELEMENT-SAFETY |
| HL730-9, HL730-9S, HL730-9SB, HL730TM-9, HL740-9B, HL740-9S, HL740-9SB, HL757-9SM, HW140, HW210, HX220NL, HX235L, R140LC9, R140LC9S, R140W9, R140W9S, R160LC9, R160LC9S, R170W9, R170W9S, R180LC9, R180L... |
| 11N6-27040 ELEMENT-PRIMARY |
| HL730-9, HL730-9S, HL730-9SB, HL730TM-9, HL740-9B, HL740-9S, HL740-9SB, HL757-9SM, HW140, HW210, HX220NL, HX235L, R140LC9, R140LC9S, R140W9, R140W9S, R160LC9, R160LC9S, R170W9, R170W9S, R180LC9, R180L... |
| 11N7-10020 ELEMENT |
| HW140, HW210, HX180L, HX220L, HX220NL, HX235L, HX260L, R125LCR-9A, R140LC9A, R140W9, R140W9A, R145CR9A, R160LC9A, R160W9A, R170W9, R180LC9A, R180W9A, R200W7, R200W7A, R210LC7, R210LC7A, R210LC9, R210L... |
| 4936636 ELEMENT-BREATHER |
| 110D-7A, 110D-9, HL740-9A, HL740-F, HL740TM-9A, HL740TM-F, HL757-9A, HL757-F, HL757TM-9A, HL757TM-F, HL760-9A, HL760-9AW, HL760-F, HW140, HW210, HX220L, HX220NL, HX235L, HX260L, HX300L, R140W9A, R160W... |
| 31Q6-20340 ELEMENT-LINE FILTER |
| HW140, HW210, HX140L, HX160L, HX180L, HX220L, HX220NL, HX235L, HX260L, HX300L, HX330L, HX380L, HX430L, HX480L, HX520L, R1200-9, R125LCR-9A, R140LC9, R140LC9A, R140LC9S, R140W9, R140W9A, R140W9S, R145C... |
| 1DFQ-20130 ELEMENT ASSY-SECONDARY |
| 35D-9, 50D-9, 80D-9 |
| 4353984 ELEMENT-CATALYST |
| 35D-9 |
| 5311117 ELEMENT-CATALYST |
| 35D-9, 50D-9, 80D-9 |
| 5311116 ELEMENT-CATALYST |
| 50D-9, 80D-9 |
| 31WD-60210 ELEMENT |
| HL757-F, HL757TM-F |
| 31Z5-60060 ELEMENT |
| SL763S |
| 31Z6-60060 ELEMENT |
| SL733S |
| 11N6-DA0090 ELEMENT-SAFETY |
| RD220-7 |
| 11N6-DA0100 ELEMENT-PRIMARY |
| RD220-7 |
| 11N1-28010 ELEMENT-INNER |
| RD220-7, RD80-7 |
| Pos. | Part No | Qty | Parts name | Comments |
| 1 | 11KA-71000 | [1] | FUEL FILTER ASSY | SINGLE F/WARMER |
| 1-1. | 11QA-71010 | [1] | HEAD ASSY | |
| 1-2. | 11KA-71040 | [1] | ELEMENT ASSY | |
| 1-3. | 11QA-71050 | [1] | BOWL ASSY | |
| 1-4. | 11QA-71020 | [1] | SENSOR ASSY-WIF | |
| 2 | S037-103026 | [2] | BOLT-W/WASHER | |
| 3 | 11M8-50030 | [1] | HOSE ASSY | |
| 5 | P020-110003 | [2] | ELBOW-90 | |
| 6 | P460-080042 | [1] | HOSE ASSY-FUEL 0X0 | |
| 7 | 1BQ6-50080 | [1] | ELBOW-90 | |
| 8 | 11Q4-50010 | [1] | VALVE-FUEL CUT | |
| 9 | 11N8-50060 | [1] | ELBOW-90 | |
| 10 | P001-095066 | [1] | HOSE-FUEL | |
| 11 | 11Q6-50200 | [1] | COOLER-FUEL | |
| 12 | S035-082026 | [4] | BOLT-W/WASHER | |
| 13 | 31L7-10220 | [6] | CLAMP-TUBE | |
| 14 | S037-102026 | [8] | BOLT-W/WASHER | |
| 15 | 11K6-50020 | [1] | HOSE-FUEL | |
| 15 | 11K6-50021 | [1] | HOSE-FUEL | |
| 17 | P392-120000 | [1] | WASHER-COPPER | |
| 18 | 11ND-40170 | [1] | CONNECTOR | |
| 19 | S520-017000 | [5] | CLAMP-HOSE | |
| 20 | 31L7-10340 | [2] | CLAMP-TUBE INS | |
| 21 | S631-018004 | [2] | O-RING | |
| 22 | P520-063044 | [1] | HOSE ASSY-FUEL | |
| 23 | 11KA-73000 | [1] | FUEL FILTER ASSY | DUAL F/WARMER |
| 23-1. | 11QA-71010 | [1] | HEAD ASSY | |
| 23-2. | 11KA-71040 | [1] | ELEMENT ASSY | |
| 23-3. | 11QA-71030 | [1] | BOWL ASSY | |
| 23-4. | 11QA-71020 | [1] | SENSOR ASSY-WIF | |
| 24 | 21QB-23500 | [1] | HARNESS-FUEL WARMER |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Advantage
1. Offer Top quality & competitive products
2. Support 12-month warranty
3. 100% tested before shipping
4. Delivery in time
5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator
6. More than 15 years production and 11 years foreign trade experience
7. Professional QC team
8. Best sales team, 24 hours service
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
Contact Person: Mr. Paul
Tel: 0086-15920526889
Fax: +86-20-89855265
