Product Details:
Payment & Shipping Terms:
|
| Engine Model: | C7.1 C9 C9.3 | Machine Model: | 330D 325C 328D LCR 330C |
|---|---|---|---|
| Product Name: | Ball | Application: | Excavator, Wheel Loader |
| Part Number: | 167-3863 1673863 | Packing: | Standard Export Carton |
| Highlight: | 167-3863 Excavator Travel Motor,325C Excavator Travel Motor,330D Excavator Travel Motor |
||
| Application | Excavator, Wheel Loader |
| Name | Ball |
| Parts No | 167-3863 1673863 |
| Machine Model | 325C 330D |
| Category | Motor GP-Travel, Pump GP-Main Hydraulic, Travel Motor |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT EMS |
| Packing | As request or standard packing |
EXCAVATOR 325C 328D LCR 330C 330C FM 330C L 330C MH 330D 330D L 330D LN 330D MH 336D 336D L 336D LN 336D2 336D2 L 336E 336E H 336E L 336E LH 336E LN 336F L 340D L 340D2 L
MOBILE HYD POWER UNIT 330D 336D L 336E HVG
WHEEL LOADER 993K.Caterpillar.
| 5P6727 BALL BEARING |
| 14M, 16M, 345C, 345C L, 345C MH, 345D, 345D L, 345D L VG, 349D, 349D L, 349E, 349E L, 349E L HVG, 349E L VG, 349F L, 621H, 621K, 623H, 623K, 623K LRC, 627H, 627K, 627K LRC, 637E, 69D, 725, 730, 730C |
| 3L1824 BALL BEARING |
| 773G, 773G OEM, 775G, 775G OEM, 776C, 776D, 777, 777B, 777D, 777F, 777G, 784B, 784C, 785, 785B, 785C, 785D, 854G, 854K, 992G, 992K, 993K, CX48-P2300, D10, D11N, D11R, D11T, D353C, SPF343C, TH48-E70 |
| 4M5227 BALL BEARING |
| 773G, 773G OEM, 775G, 775G OEM, 776C, 776D, 777D, 784B, 785B, 854G, 854K, 992G, 992K, 993K, CX48-P2300, D10, D11N, D11R, D11T, D8H, SPF343C, TH48-E80 |
| 1486559 BALL BEARING |
| 784B, 784C, 785B, 785C, 785D, 789, 789B, 789C, 789D, 793B, 793C, 793D, 793F, 793F CMD, 793F OEM, 793F-XQ, 797, 797B, 797F, 844, 844H, 844K, 854G, 854K, 990, 990 II, 990H, 990K, 992C, 992G, 992K, 993K |
| 3K2518 BALL BEARING |
| 578, 583R, 589, 627, 627B, 627E, 627F, 627G, 627H, 627K, 627K LRC, 637B, 637D, 637E, 637G, 826C, 834B, 834G, 834H, 834K, 836, 836G, 836H, 836K, 844, 844H, 844K, 854G, 854K, 902, 906, 906H, 906H2 |
| Pos. | Part No | Qty | Parts name | Comments |
| 1 | 1T-0936 | [1] | PLUG-ORIFICE | |
| 2 | 4B-4158 | [4] | SCREW-DRIVE (NO 4X0.25-IN) | |
| 3 | 6V-3382 J | [1] | SEAL-LIP TYPE | |
| 4 | 8J-2559 | [1] | PLATE-WARNING (OIL FILL) | |
| 5 | 087-4786 | [1] | ADAPTER | |
| 6 | 108-6503 | [9] | PISTON AS | |
| 7 | 118-4057 | [9] | SPRING | |
| 8 | 124-1541 | [2] | PIN | |
| 9 | 124-1561 | [20] | SPRING-BRAKE | |
| 10 | 137-3708 | [1] | RETAINER | |
| 11 | 167-3855 | [1] | SHAFT | |
| 12 | 167-3857 | [1] | KEY | |
| 13 | 167-3858 | [1] | KEY | |
| 14 | 167-3859 | [1] | PLATE-CAM | |
| 15 | 167-3862 | [1] | PLATE-RETAINER | |
| 16 | 167-3863 | [1] | BALL | |
| 17 | 167-3865 | [5] | PLATE-SEPARATOR | |
| 18 | 167-3866 | [4] | PLATE-FRICTION | |
| 19 | 167-3867 | [1] | PLATE-PORT | |
| 20 | 167-3868 | [1] | PISTON-BRAKE | |
| 21 | 167-3872 | [1] | SPOOL | |
| 22 | 170-1612 J | [2] | SEAL | |
| 23 | 170-1626 J | [1] | RING-BACKUP | |
| 24 | 170-1627 J | [1] | RING-BACKUP | |
| 25 | 173-4063 | [1] | BARREL AS-MOTOR | |
| 26 | 173-4066 | [1] | SPACER (63.05X79.8X7-MM THK) | |
| 27 | 175-7436 | [1] | VALVE | |
| 28 | 175-7887 | [2] | DOWEL | |
| 29 | 180-6769 | [1] | BEARING AS | |
| 30 | 180-6770 | [1] | BEARING AS | |
| 31 | 186-5175 | [1] | PLUG | |
| 32 | 193-7901 | [1] | BODY AS | |
| 124-1555 | [4] | PLUG | ||
| 33 | 271-6377 | [1] | HEAD AS | |
| 096-5916 | [2] | SEAT | ||
| 124-1555 | [4] | PLUG | ||
| 34 | 274-4512 | [1] | SEAT | |
| 35 | 274-4513 | [2] | RETAINER | |
| 36 | 345-3744 | [1] | PISTON-ACTUATOR | |
| 37 | 095-1572 J | [2] | SEAL-O-RING | |
| 38 | 095-1585 J | [1] | SEAL-O-RING | |
| 39 | 095-1596 J | [1] | SEAL-O-RING | |
| 40 | 095-1700 J | [2] | SEAL-O-RING | |
| 41 | 095-7380 | [1] | SPRING | |
| 42 | 096-3978 | [1] | SPRING | |
| 43 | 096-5919 J | [2] | RING-BACKUP | |
| 44 | 099-7030 J | [1] | RING-BACKUP | |
| 45 | 170-1616 J | [1] | SEAL | |
| 46 | 2D-6642 | [2] | BALL | |
| 47 | 2M-9780 J | [1] | SEAL-O-RING | |
| 48 | 2R-1236 | [1] | RING-RETAINING (LOCK, INTERNAL) | |
| 49 | 3D-2824 J | [2] | SEAL-O-RING | |
| 50 | 3K-0360 J | [2] | SEAL-O-RING | |
| 51 | 4K-4284 | [1] | RING-RETAINING | |
| 52 | 6V-5192 M | [4] | BOLT-SOCKET HEAD (M8X1.25X30-MM) | |
| 53 | 7Y-5219 J | [2] | SEAL-O-RING | |
| 54 | 8T-2393 M | [8] | BOLT-SOCKET HEAD (M16X2X60-MM) | |
| 55 | 9S-8005 | [2] | PLUG (3/4-16-THD) | |
| 56 | 9S-8008 | [2] | PLUG (1-1/16-12-THD) | |
| AVAILABLE REPAIR KIT(S): | ||||
| 272-0290 J | [1] | KIT-SEAL (TRAVEL MOTOR) | ||
| J | KIT MARKED J SERVICES PART(S) MARKED J | |||
| M | METRIC PART |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
