Product Details:
Payment & Shipping Terms:
|
| Model Number: | R450LC7 R500LC7 R480LC9 R520C9 | Part Number: | 4089478 |
|---|---|---|---|
| Product Name: | Overhaul Gasket Kit | Engine Model: | QSM11 |
| Packing: | Standard Export Carton | Warranty: | 6/12 Months |
| High Light: | R480LC-9 Excavator Engine Parts,4089478 Excavator Engine Parts,QSM11 Overhaul Gaket Kit |
||
Specification
| Category | HYUNDAI Excavator Engine parts |
| Name | Overhaul Gasket Kit |
| Parts No | 4089478 |
| Machine Model | R450LC-7 R500LC-7 R480LC-9 R520LC-9 |
| Engine model | QSM11 |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT EMS |
| Packing | As request or standard packing |
| Pos. | Part No | Qty | Parts name | Comments |
| *. | 4089478 | [1] | SET-UPPER ENG GASKET | |
| 1 | 3037537 | [1] | O-RING | NOT SHOWN |
| 2 | 3040817 | [1] | O-RING | NOT SHOWN |
| 3 | 3042401 | [1] | SEAL-GROMMET | NOT SHOWN |
| 4 | 3069786 | [1] | GASKET-INTAKE | NOT SHOWN |
| 5 | 3070136 | [6] | O-RING | RED, NOT SHOWN |
| 6 | 3070137 | [6] | O-RING | WHITE, N/SHOWN |
| 7 | 3070138 | [6] | O-RING | BLUE,NOT SHOWN |
| 8 | 3088984 | [1] | GASKET-TURBO | NOT SHOWN |
| 9 | 3102361 | [1] | GASKET-CONNECTION | NOT SHOWN |
| 10 | 3102802 | [1] | SEAL/O-RING | NOT SHOWN |
| 11 | 3328328 | [7] | WASHER-SEALING | NOT SHOWN |
| 12 | 3328464 | [2] | SEAL-RECT RING | NOT SHOWN |
| 13 | 3328948 | [6] | GASKET-EXH MANI | NOT SHOWN |
| 14 | 3627695 | [2] | SEAL/O-RING | NOT SHOWN |
| 15 | 3678786 | [2] | O-RING | NOT SHOWN |
| 16 | 3678912 | [1] | O-RING | NOT SHOWN |
| 17 | 3755843 | [1] | GASKET-TURBO | NOT SHOWN |
| 18 | 3819871 | [1] | O-RING | NOT SHOWN |
| 19 | 3819900 | [1] | GASKET-TURBOCHARGER | NOT SHOWN |
| 20 | 3820872 | [1] | GASKET-COVER PLATE | NOT SHOWN |
| 21 | 3867043 | [19] | SEAL-O RING | NOT SHOWN |
| 22 | 3883220 | [1] | GASKET-R/LEVER COVER | NOT SHOWN |
| 23 | 3899343 | [1] | GASKET-TURBO | NOT SHOWN |
| 24 | 3922794 | [2] | O-RING | NOT SHOWN |
| 25 | 4022907 | [3] | SCREW-HEX FLG H/CAP | NOT SHOWN |
| 26 | 4973102 | [1] | GASKET-LEVER HOUSING | NOT SHOWN |
| 27 | 4022500 | [1] | GASKET-CYLINDER HEAD | NOT SHOWN |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
1. Warranty Period: 3 Months' warranty from the date of arrival. Longer period of 6 months' warranty could be offered with higher price level.
2. Warranty type: replacement of the parts that have quality problem.
3. Warranty is not valid for below s
* Cutomer give wrong information about the order
* Force Majeure
* Wrong installation and operation
* Rust because of wrong stock & maintenance
