| Product name |
Coupling |
| Part number |
1912645 191-2645 |
| Model |
330C 330D 336D 336E |
| Category group |
Excavator Final Drive Parts |
| MOQ |
1 PCS |
| Warranty |
6 months |
| Payment term |
T/T, Western Union, MoneyGram |
| Delivery time |
1-3 days after receiving the payment |
| Packing |
As request or standard packing |
| Means of transport |
By sea/air, DHL |
- More coupling for final drive parts
1546643 COUPLING & MTG GP-PUMP
1090, 1190, 1190T, 1290T, 2290, 2390, 2391, 2491, 2590, 330C, 330C FM, 330C L, 330C MH, 345B L, 511, 521, 521B, 522, 522B, 532, 541, 541 2, 551, 552, 552 2, TK711, TK721, TK722, TK732, TK741, TK751, T...
2870169
2870169 COUPLING GP-FLEXIBLE
330D, 330D FM, 330D L, 330D LN, 330D MH, 336D, 336D L, 336D LN, M330D
8S7169
8S7169 COUPLING
10 FT, 10-20B, 215, 215D, 225, 225D, 227, 229, 229D, 231D, 235, 235C, 245, 245B, 24H, 3116, 325B L, 325C, 325D L, 330B L, 330C, 330D L, 336D L, 3406E, 345B II, 345B L, 345C L, 365B, 365B II, 365C, 365...
1807100
1807100 COUPLING-GENERATOR
325C, 325D MH, 330B L, 330C L, 330C MH, 330D MH, 345B, 345B II MH, M325B, M325C MH, M325D L MH, M325D MH, MH3037, W330B, W345B II
2409432
2409432 COUPLING AS
325C, 325D L, 330C, 330D L, 345B II, 345C L, 365B II, 365C, 365C L, 385B, 385C L
2409433
2409433 COUPLING AS
325C, 325D L, 330C, 330D L, 345B II, 345C L, 365B II, 365C, 365C L, 385B, 385C L
2409426
2409426 COUPLING AS
325C, 325D L, 330C, 330D L, 345B II, 345C L, 365B II, 365C, 365C L, 385B, 385C L
2409428 COUPLING AS
325C, 325D L, 330C, 330D L, 345B II, 345C L, 365B II, 365C, 365C L, 385B, 385C L
2666257 COUPLING GP-FLEXIBLE
330D L, 330D LN
1851244
1851244 COUPLING AS
330D L, M330D
3964439 COUPLING GP-FLEXIBLE
336F L
2241699 COUPLING AS
330C L
3482156 COUPLING-FLEXIBLE
3533236 COUPLING-FLEXIBLE
3520483 COUPLING-FLEXIBLE
2649554 COUPLING
BR272
2649054
2649054 COUPLING
BR272
2735499 COUPLING
120M, 120M 2, 12M 2, 12M 3 AWD, 140M, 140M 2, 140M 3 AWD, 160M, 160M 2, 160M 3 AWD
3242101 COUPLING
4428771 COUPLING AS-DRIVE
120M 2, 12M 2, 12M 3, 12M 3 AWD, 140M 2, 140M 3, 140M 3 AWD, 160M 2, 160M 3, 160M 3 AWD
1507999 COUPLING AS-PERMANENT
120M, 140M, 160M
3687795 COUPLING AS
CWAC-40
3686770 COUPLING AS
CWAC-40
2585618 COUPLING
TA19-M2WD
- catalog parts list diagram
Pos. Part No Qty Parts name Comments
1. 3E-2338 [2] PLUG-PIPE
2. 7Y-0639 [1] GEAR-SUN (21-TEETH)
3. 7Y-0642 [1] GEAR-RING (63-TEETH)
4. 7Y-0645 [1] CARRIER
5. 7Y-0659 [3] GEAR-PLANETARY (22-TEETH)
6. 7Y-0661 [3] SHAFT-PLANETARY
7. 7Y-0662 [4] SHAFT-PLANETARY
8. 7Y-0663 [4] GEAR-PLANETARY (20-TEETH)
9. 7Y-0667 [1] RING-RETAINING
10. 7Y-0673 [1] GEAR-RING (73-TEETH)
11. 7Y-0676 [3] GEAR-PLANETARY (24-TEETH)
12. 7Y-0731 [1] CARRIER AS
12A. 7Y-0656 [3] SHAFT-PLANETARY
13. 7Y-1094 M [14] WASHER (66X102X1-MM THK)
14. 7Y-5235 M [20] BOLT (M24X3X190-MM)
15. 094-0577 B [1] PLATE (7-MM THK)
16. 094-0578 B [1] PLATE (8-MM THK)
17. 094-0579 B [1] PLATE (9-MM THK)
18. 094-0580 B [1] PLATE (10-MM THK)
19. 110-7231 [1] GEAR-SUN (18-TEETH)
20. 191-2521 [1] GEAR-SUN (23-TEETH)
21. 196-4873 J [2] BEARING AS-BALL
22. 199-4582 [3] BEARING AS
23. 199-4583 [11] BEARING AS
24. 199-4748 J [1] HOUSING-MOTOR
25. 199-4750 [1] CARRIER-PLANETARY
26. 213-4737 J [1] SEAL GP-DUO-CONE
27. 227-6100 J [1] RETAINER
28. 227-6101 J [2] PLATE-WASHER
29. 227-6102 J [2] DOWEL
30. 093-1731 [1] RING-RETAINING
31. 094-0584 [6] WASHER (40.3X72X1-MM THK)
32. 095-0891 [7] PIN-SPRING
33. 096-3216 M [2] SETSCREW-SOCKET (M12X1.75X12-MM)
34. 191-2526 [1] COVER
35. 191-2645 [1] COUPLING
36. 199-4580 J [1] HOUSING
37. 2P-3628 [1] SEAL-O-RING
38. 7M-8485 [2] SEAL-O-RING
39. 7Y-0595 [2] SPACER (58X79.6X6-MM THK)
40. 7Y-0644 [1] SPACER (163X190X8-MM THK)
41. 8T-0293 JM [2] BOLT (M12X1.75X20-MM)
42. 8T-4167 [20] WASHER-HARD (26X44X4-MM THK)
43. 8T-4240 [3] RING-RETAINING
44. 9X-6032 M [12] BOLT-SOCKET HEAD (M10X1.5X30-MM)
45. 1U-8846 B SEALANT-GASKET
AVAILABLE REPAIR KIT(S):
227-6112 J HOUSING GP-MOTOR
B USE AS REQUIRED
J KIT MARKED J SERVICES PART(S) MARKED J
M METRIC PART
