- 3918685 Air Transfer Pipe Generator Set Engine Parts Fitting For 6BT 6BTA 4BT
| Name |
Air Transfer Pipe |
| Parts No |
3918685 |
| Machene Model |
R215LC7 R235LCR9 R235LCR9A |
| Engine |
6BT 6BTA 4BT |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT EMS |
| Packing |
As request or standard packing |
| 1.Conduct turbocharged air flow: It acts as an air passage connecting the turbocharger outlet and engine intake manifold, smoothly delivering compressed air into engine cylinders to support combustion. It is widely used on ISDE / QSB / 6BT series engines for excavators and heavy trucks. |
| |
| 2.Maintain air-tight sealing: The elbow pipe ensures no leakage of pressurized intake air. Air leakage will cause insufficient boost pressure, reduced engine power and increased fuel consumption. |
| |
| 3.Withstand high temperature & pressure: Made of cast aluminum material, it can resist high temperature and vibration from turbocharged hot air under heavy-duty working conditions. |
| |
| 4.Mounting port for sensors: The reserved hole on the pipe is used for installing pressure/temperature sensors, feeding real-time intake parameter signals to the engine controller. |
| |
| 5.Spatial transition: Its bent elbow design changes airflow direction to fit limited installation space inside engine compartment. |
