- 4487692 O-Ring HITACHI Excavator Spare Parts Fitting For ZX850-3 ZX870H-3 EX1200-6
| Appliion |
Excavator Tractor |
| Name |
o-ring |
| Parts No |
4487692 |
| Machine Model |
EX1200-5 EX1200-6 EX1900-6 ZX1800K-3 ZX850-3 ZX850-3F |
| Category |
Arm Parts |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT EMS |
| Packing |
As request or standard packing |
| 1.Primary sealing function |
| This toroidal elastomer O-ring is installed in the gland groove between two mating components. It relies on elastic compression to fill gaps, forming a tight barrier. It prevents leakage of hydraulic oil, engine oil, coolant or other working media from the internal system, and stops external dust, dirt, water and impurities from entering the assembly. |
| |
| 2.Self-energizing sealing performance |
| When system pressure rises, the medium pressure pushes the O-ring tightly against the sealing surface. The sealing force increases automatically with pressure, maintaining stable sealing under fluctuating working pressure in construction machinery hydraulic or engine systems. |
| |
| 3.Protect equipment & maintain system pressure |
| It keeps the working pressure stable inside hydraulic circuits, pumps, valves or connectors. Fluid loss is avoided, reducing power loss and preventing abnormal wear of precision internal parts caused by contaminants infiltration, thus extending service life of the whole assembly. |
| |
| 4.Compensation for minor surface defects |
| The elastic material can compensate for tiny surface irregularities, slight thermal expansion and assembly tolerances between mating metal parts, ensuring continuous sealing during temperature changes and machine vibration. |
EX1200-5 EX1200-5C EX1200-5D EX1200-6 EX1900-6 ZX1800K-3 ZX850-3 ZX850-3F ZX870-5G ZX870H-3 ZX870H-3-HCMC ZX870H-3F ZX870H-5G ZX870LC-5B ZX870LC-5G ZX870LCH-5G ZX870LCR-5G ZX870R-3 ZX870R-3F Hitachi
- More other o-ring fit for HITACHI machine
| 0964503 O-RING |
| HR750SM, VR308, VR308-2, VR408, VR408-2, ZR600TS, ZR800TS, ZX40U-3, ZX40U-3U, ZX40U-5A, ZX48U-3, ZX48U-3F, ZX50U-3, ZX50U-3F, ZX50U-3U, ZX50U-5A, ZX50U-5N, ZX52U-3, ZX52U-3F, ZX55UR-3, ZX55UR-3D |
| |
| 0961520 O-RING |
| ZX330, ZX330-3, ZX350H, ZX350K, ZX350K-3, ZX350LC-3-HCME, ZX350LC-AMS, ZX350LC-HCME, ZX360LC-3-HCMC, ZX370MTH, ZX450, ZX450H |
| |
| 979231 O-RING |
| ZX450-3, ZX470H-3 |
| |
| 1186301 O-RING |
| ZX40U-3, ZX40U-3U, ZX40U-5A, ZX40UR-3, ZX40UR-3D, ZX40WM-3D, ZX48U-3, ZX48U-3F, ZX50U-3, ZX50U-3F, ZX50U-3U, ZX50U-5A, ZX50U-5N, ZX50UNA-3, ZX52U-3, ZX52U-3F, ZX55UR-3, ZX55UR-3D, ZX60USB-3 |
| |
| 4633060 O-RING |
| ZX330 |
| |
| 1151015 O-RING |
| EX100, EX100-2, EX100-5, EX120, EX120-2, EX120-5 JPN, EX150, EX160WD, EX200, EX200-2, EX200-3, EX200-5 JPN, EX220, EX220-2, EX220-5 JPN, EX270, EX300, EX300-5, EX400-5, EX60, EX60-2, EX60-3 |
| |
| 129900-32030 O-RING P20 |
| ZX60USB-3F, ZX65USB-3F |
| |
| 215904 O-RING |
| ZX450-3, ZX470H-3 |
| |
| 0974102 O-RING |
| ZX16-3, ZX17U-2, ZX17UNA-2 |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 0 |
9213149 |
[1] |
ARM ASS'Y |
|
| 00A. |
5008052 |
[1] |
ARM |
|
| 00B. |
4259297 |
[2] |
BUSHING |
|
| 00C. |
4258580 |
[2] |
SEAL;DUST |
|
| 00D. |
3094967 |
[2] |
BUSHING |
|
| 00E. |
4287858 |
[2] |
SEAL;DUST |
|
| 00F. |
4259255 |
[2] |
BUSHING |
|
| 00G. |
4251207 |
[2] |
SEAL;DUST |
|
| 00H. |
4259256 |
[2] |
BUSHING |
|
| 00I. |
4222972 |
[1] |
NAME-PLATE |
|
| 00J. |
M492564 |
[4] |
SCREW;DRIVE |
|
| 00K. |
3095078 |
[2] |
PLATE;THRUST |
|
| 00L. |
M341020 |
[8] |
BOLT;SOCKET |
|
| 00M. |
J401640 |
[8] |
PIN;KNOCK |
|
| 4 |
8078143 |
[1] |
PIN |
|
| 5 |
4179432 |
[1] |
PLATE |
|
| 6 |
J932045 |
[2] |
BOLT |
|
| 7 |
A590920 |
[2] |
WASHER;SPRING |
|
| 9 |
9094657 |
[1] |
LINK |
(R) ASS'Y |
| 09A. |
8048255 |
[1] |
LINK |
|
| 09B. |
4258661 |
[1] |
BUSHING |
|
| 09C. |
4258662 |
[1] |
BUSHING |
|
| 10 |
8048269 |
[1] |
PIN |
|
| 11 |
9094658 |
[1] |
LINK |
(L) ASS'Y |
| 11A. |
8048256 |
[1] |
LINK |
|
| 11B. |
4258661 |
[1] |
BUSHING |
|
| 11C. |
4258662 |
[1] |
BUSHING |
|
| 13 |
J932050 |
[3] |
BOLT |
|
| 14 |
A590920 |
[3] |
WASHER;SPRING |
|
| 15 |
J75481 |
[2] |
FITTING;GREASE |
|
| 16 |
4393380 |
[1] |
STOPPER |
|
| 17 |
A811160 |
[2] |
O-RING |
|
| 18 |
8048270 |
[1] |
PIN |
|
| 19 |
9094825 |
[2] |
LINK ASS'Y |
|
| 19A. |
2030178 |
[1] |
LINK |
|
| 19B. |
4258783 |
[1] |
BUSHING |
|
| 19C. |
4251766 |
[1] |
SEAL;DUST |
|
| 19D. |
4258784 |
[1] |
BUSHING |
|
| 19E. |
4258579 |
[2] |
SEAL;DUST |
|
| 19F. |
J75481 |
[1] |
FITTING;GREASE |
|
| 20 |
9751991 |
[1] |
SPACER |
|
| 22 |
J932050 |
[3] |
BOLT |
|
| 23 |
A590920 |
[3] |
WASHER;SPRING |
|
| 24 |
4393386 |
[1] |
STOPPER |
|
| 25 |
3095077 |
[1] |
PIN |
|
| 31 |
4136522 |
[2] |
O-RING |
|
| 31 |
4485883 |
[2] |
O-RING |
|
| 33 |
4393383 |
[1] |
STOPPER |
|
| 34 |
8048272 |
[1] |
PIN |
|
| 36 |
J932050 |
[3] |
BOLT |
|
| 37 |
A590920 |
[3] |
WASHER;SPRING |
|
| 38 |
4129741 |
[2] |
O-RING |
|
| 38 |
4487692 |
[2] |
O-RING |
|
| 39 |
J75481 |
[4] |
FITTING;GREASE |
|
| 40 |
4287472 |
[2] |
RING |
|
| 41 |
8078146 |
[1] |
PIN |
|
| 42 |
4179432 |
[1] |
PLATE |
|
| 43 |
J932045 |
[2] |
BOLT |
|
| 44 |
A590920 |
[2] |
WASHER;SPRING |
|
| 46 |
4130686 |
[8] |
COLLAR |
|
| 47 |
4105912 |
[8] |
CAP |
|
| 50 |
4472605 |
[1] |
CYL.;BUCKET |
|
| 63 |
4271607 |
[2] |
RING |
|
