7T-3343 7T3343 Clutch Plate Excavator Spare Parts For 950H 960F 962G 962H 966C

Large Image : 7T-3343 7T3343 Clutch Plate Excavator Spare Parts For 950H 960F 962G 962H 966C

Product Details:

Place of Origin:	China
Brand Name:	OEM
Model Number:	7T-3343 7T3343

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	20-55 USD
Packaging Details:	Wooden box for heavy parts, paper carton for light parts
Delivery Time:	3-7 working days
Payment Terms:	T/T, D/P, D/A,Western Union, L/C,
Supply Ability:	100-2000

Contact Now

Detailed Product Description

Machine Model:	950G 950H 960F 962G 962H 966C 966H	Engine Model:	3176
Product Name:	Clutch Plate	Appliion:	Excavator
Part Number:	7T-3343 7T3343	Packing:	Standard Export Carton
Highlight:	950H excavator clutch plate , 960F clutch plate spare part , 966C excavator replacement clutch

7T-3343 7T3343 Clutch Plate Excavator Spare Parts For 950H 960F 962G 962H 966C

Specifiion

Name	Clutch Plate
Parts No	7T-3343 7T3343
Machine Model	950G 950G II 950H 960F 962G 962G II 962H 966C 966H 966K
Category	Planetary Gp-Transmission
Lead time	1-3 DAYS
Quality	Brand new, OEM quality
MOQ	1 PCS
Means of transport	By sea/air, DHL FEDEX UPS TNT EMS
Packing	As request or standard packing

Function

1.Torque transmission & power connection/disconnection Works together with friction discs in the planetary clutch pack. When hydraulic pressure is applied, it clamps friction plates to transmit engine torque to planetary gear sets; when pressure releases, power flow is cut off for gear shifting.

2.Reaction force bearing As a steel reaction plate, it bears the clamping thrust from hydraulic piston, provides rigid backing for friction discs, maintains uniform pressure across the friction surface.

3.Control clutch clearance It defines the precise air gap between clutch plates. Keep proper clearance to prevent drag when clutch is disengaged and ensure full contact during engagement.

4.Resist heavy impact load Made of heat-treated hardened steel. It withstands frequent shock loads, torque spikes during forward/reverse shift and heavy digging cycles.

5.Stable heat distribution Conduct friction heat away from contact surfaces during slipping and shifting, reduce local overheating of friction material.

Compatible models

CHALLENGER 65 65C 65E 75 75C 75D 75E 85C 85D 85E 95E
INTEGRATED TOOLCARRIER IT62G IT62G II
LOAD HAUL DUMP R1300G II
WHEEL LOADER 950F II 950G 950G II 950H 960F 962G 962G II 962H 966C 966H 966K

More other plate parts fit for HYUNDAI machine

24L3-30710 PLATE

100D-7, 110D-7E, 15BT-9, 16B-9, 180D-9, 22B-9, 22BH-9, 250D-9, 40B-9, 50D-7A, 50D-7K, 50DE, 50DEACE, 50DF, 80D-9, 80DE, 80DEACE, H70, H80, HL720-3, HL720-3C, HL730-7, HL730-7A, HL7303, HL7303C, HL730T...

21EM-45070 PLATE-VANE

33HDLL, 42HDLL, HX180L, R110-7, R110-7A, R125LCR-9A, R130LC3, R130W3, R140LC-7, R140LC-7A, R140LC9, R140LC9A, R140LC9S, R140W7, R140W7A, R140W9, R140W9A, R140W9S, R145CR9, R145CR9A, R160LC3, R160LC7, ...

72N6-05040 PLATE-HINGE

HX180L, HX235L, R110-7, R110-7A, R1200-9, R125LCR-9A, R140LC-7, R140LC-7A, R140LC9, R140LC9A, R140W7, R140W7A, R140W9, R140W9A, R145CR9, R145CR9A, R160LC7, R160LC7A, R160LC9, R160LC9A, R160W9A, R170W7...

72N6-05050 PLATE-HANDLE

HW140, HW210, HX140L, HX160L, HX180L, HX220L, HX220NL, HX235L, HX260L, HX300L, HX330L, HX380L, HX430L, HX480L, HX520L, R110-7, R110-7A, R1200-9, R125LCR-9A, R140LC-7, R140LC-7A, R140LC9, R140LC9A, R14...

75N4-03330 PLATE

HX180L, HX235L, R1200-9, R125LCR-9A, R140LC9, R140LC9A, R140W9, R140W9A, R145CR9, R145CR9A, R160LC9, R160LC9A, R160W9A, R170W9, R180LC9, R180LC9A, R180W9A, R210LC9, R210NLC9, R210W-9, R210W9A, R210W9A...

71Q6-04960 PLATE

HX180L, HX235L, R1200-9, R125LCR-9A, R140LC9, R140LC9A, R140LC9S, R140W9, R140W9A, R140W9S, R145CR9, R145CR9A, R160LC9, R160LC9A, R160LC9S, R160W9A, R170W9, R170W9S, R180LC9, R180LC9A, R180LC9S, R180W...

XKAY-00538 PLATE

HX160L, HX180L, R160LC7, R160LC7A, R160LC9, R160LC9A, R160LC9S, R160W9A, R170W7, R170W7A, R170W9, R170W9S, R180LC7, R180LC7A, R180LC9, R180LC9A, R180LC9S, R180W9A, R180W9S, R200W7, R200W7A, R210LC7, R...

21Q6-60030 PLATE

R1200-9, R210LC9, R210LC9BC, R210LC9BH, R210NLC9, R210W-9, R210W9A, R210W9AMH, R210W9MH, R210W9S, R220LC9A, R220NLC9A, R250LC9, R250LC9A, R260LC9S, R290LC9, R290LC9MH, R300LC9A, R300LC9S, R300LC9SH, R...

71Q6-21270 PLATE WA

HX180L, R1200-9, R140LC9, R140LC9A, R140LC9S, R140W9A, R160LC9, R160LC9A, R160LC9S, R160W9A, R180LC9, R180LC9A, R180LC9S, R180W9A, R210LC9, R210LC9BC, R210LC9BH, R210NLC9, R220LC9A, R220NLC9A

Catalog parts list

Pos.	Part No	Qty	Parts name	Comments
1	0L-1558	[1]	BOLT (1/2-20X3.25-IN)
2	5D-6141	[1]	RETAINER
3	2H-2665	[1]	SEAL-O-RING
4	9W-2147	[1]	YOKE AS
5	3S-9880	[1]	GUARD
6	9F-5088	[1]	SEAL-LIP TYPE
7	0S-1594	[6]	BOLT (3/8-16X1-IN)
8	9W-2799	[1]	COVER
9	1U-8846 B		SEALANT-GASKET
10	7T-9759	[1]	ROTOR-SENSOR (70 TEETH)
11	8E-3963	[1]	BEARING AS-ROLLER
12	006-7241	[1]	RING
13	3J-1907	[2]	SEAL-O-RING
14	2P-1294	[1]	PLUG-SEAL
15	105-4364 C	[1]	HOUSING-CLUTCH
16	1D-4569	[21]	BOLT (1/2-13X4.25-IN)
17	4J-1253	[1]	SEAL-O-RING
18	8M-4988	[1]	SEAL-O-RING
19	7T-6356	[1]	CARRIER AS
	2D-6642	[4]	BALL
20	7M-3916	[1]	BUSHING
21	3N-9423	[1]	SEAL-RING
22	3S-8109	[4]	PIN-SPRING
23	7T-3060	[4]	SHAFT-PLANETARY
24	7T-5273	[4]	GEAR-PLANETARY (29-TEETH)
	5P-8451	[4]	BEARING
25	8E-8303	[8]	DISC-THRUST
26	8E-8302	[1]	DISC-THRUST
27	7T-6357	[1]	DISC-THRUST
28	1P-9216	[1]	RING-SEAL
29	7T-5507	[1]	SEAL-RING
30	7T-5334	[1]	PISTON
31	8P-1656	[4]	PLATE-CLUTCH
32	6Y-2027	[4]	DISC-FRICTION
33	2L-3845 C	[5]	DOWEL
34	5J-9104	[5]	SPRING
35	1S-9989	[5]	DOWEL-REACTION
36	7T-5271	[1]	GEAR-RING (84-TEETH)
37	9S-4191	[2]	PLUG-O-RING
38	8E-6627	[1]	HOUSING-CLUTCH
39	1T-0765	[2]	BOLT (3/8-16X1-IN)
40	4J-1253	[1]	SEAL-O-RING
41	1M-3937	[1]	RING-METAL SEAL
42	9W-9404	[1]	CARRIER AS
	2D-6642	[2]	BALL
43	102-2176	[2]	RING-LOCK
44	3N-9423	[2]	SEAL-RING
45	4H-7925	[1]	RING-METAL SEAL
46	7G-5675	[2]	RING-SEAL
47	6P-7773	[2]	RING-SEAL
48	7T-1270	[4]	SHAFT-PLANETARY
49	8E-8303	[8]	DISC-THRUST
50	7T-1286	[4]	GEAR-PLANETARY (26-TEETH)
	5P-8451	[4]	BEARING
51	3S-8109	[8]	PIN-SPRING
52	6T-6987	[1]	PISTON-CLUTCH
53	7T-3343	[8]	PLATE-CLUTCH
54	7T-3456	[7]	DISC-FRICTION
55	5J-9104	[4]	SPRING
56	8E-6629	[1]	GEAR-RING (75 TEETH)
57	8E-6628	[1]	HOUSING-CLUTCH
58	9W-8491	[1]	CARRIER AS
	2D-6642	[2]	BALL
59	7T-1271	[4]	SHAFT-PLANETARY
60	8E-8298	[8]	DISC-THRUST
61	7T-1285	[4]	GEAR-PLANETARY (23-TEETH)
	7S-4534	[4]	BEARING-CAGED
62	7T-4569	[1]	GEAR-RING (90 TEETH)
63	8E-6630	[1]	PISTON-CLUTCH
64	5P-9862	[2]	RING
65	7T-1277	[2]	GEAR-SUN (42-TEETH)
66	3S-3440	[2]	WASHER-WAVE (68.1X80.8X0.5-MM THK)
67	9F-3823	[2]	RING-SEAL
68	7T-4529	[1]	CARRIER-RING
69	8E-4886	[1]	CARRIER-PLANETARY
70	2S-3567	[3]	BOLT-12 POINT HEAD (3/8-16X2.75-IN)
71	7T-1271	[3]	SHAFT-PLANETARY
72	8E-8298	[6]	DISC-THRUST
73	7T-1285	[3]	GEAR-PLANETARY (23-TEETH)
	7S-4534	[3]	BEARING-CAGED
74	3S-8109	[3]	PIN-SPRING
75	135-1993	[1]	PLATE-CENTER
76	7T-3343	[3]	PLATE-CLUTCH
77	7T-3456	[2]	DISC-FRICTION
78	7J-5938	[4]	SPRING
79	6T-6987	[1]	PISTON-CLUTCH
80	6P-7773	[1]	RING-SEAL
81	7G-5675	[1]	RING-SEAL
82	8E-5295	[1]	GEAR AS (90-TEETH)
	6V-4431	[9]	PLUG-CUP
83	7T-1279	[1]	CAGE-BEARING
84	1S-0579	[1]	BALL BEARING
85	7T-1283	[1]	PLATE-RETAINER
86	7T-5272	[1]	SHAFT-CENTER
87	5V-9266	[4]	ROD
88	7T-4883	[1]	SHAFT AS
	7T-4251	[1]	BUSHING
89	8E-4887	[1]	HOUSING-CLUTCH
90	5P-8245	[8]	WASHER-HARD (13.5X25.5X3-MM THK)
91	8T-1121	[6]	BOLT (1/2-13X8.75-IN)
92	2M-8868	[1]	RACE-BEARING OUTER
93	2A-1531	[2]	BOLT (1/2-13X6.5-IN)
	B		USE AS REQUIRED
	C		CHANGE FROM PREVIOUS TYPE
	R		REMFG PART MAY BE AVAILABLE

7T-3343 7T3343 Clutch Plate Excavator Spare Parts For 950H 960F 962G 962H 966C

We could supply the following spare parts

1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.

2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.

3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.

4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.

5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.

6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.

Advantage

1. Offer Top quality & competitive products

2. Support 12-month warranty

3. 100% tested before shipping

4. Delivery in time

5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator

6. More than 15 years production and 11 years foreign trade experience

7. Professional QC team

8. Best sales team, 24 hours service

Packing and Shipping

Packing Details :

inner packing : plastic film for wrapping

external packing : wooden

Shipping :

within 3 days after received the payment , by air or by express or by sea on the basis of the

quantity and emergency circumstances.

1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,

2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.

3. By Sea: Delivery from the Huangpu port .
