7T-3456 7T3456 Clutch Disc Wheel Loader Spare Parts Fit For 950H 960F 962G 966C

Large Image : 7T-3456 7T3456 Clutch Disc Wheel Loader Spare Parts Fit For 950H 960F 962G 966C

Product Details:

Place of Origin:	China
Brand Name:	OEM
Model Number:	7T-3456 7T3456

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	USD 15-40
Packaging Details:	Wooden box for heavy parts, paper carton for light parts
Delivery Time:	3-7 working days
Payment Terms:	T/T, D/P, D/A,Western Union, L/C,
Supply Ability:	100-2000

Contact Now

Detailed Product Description

Category:	Planetary Gp-Transmission	Machine Model:	950F II 950G 950G II 950H 960F 962G 966C
Appliion:	Wheel Loader, Tractor	Product Name:	Clutch Disc
Part Number:	7T-3456 7T3456	Packing:	Standard Export Carton
Highlight:	Clutch Disc for 950H Wheel Loader , 7T3456 Clutch Disc replacement part , Wheel Loader Spare Parts with warranty

7T-3456 7T3456 Clutch Disc Wheel Loader Spare Parts Fit For 950H 960F 962G 966C

Specifiion

Name	Clutch Disc
Parts No	7T-3456 7T3456
Machine Model	950F II 950G 950G II 950H 960F 962G 962G II 962H 966C 966H 966K
Engine Model	3176
Lead time	1-3 DAYS
Quality	Brand new, OEM quality
MOQ	1 PCS
Means of transport	By sea/air, DHL FEDEX UPS TNT EMS
Packing	As request or standard packing

Functions

1.Torque transmission & power engagement It is the friction disc inside the planetary transmission clutch pack. When hydraulic pressure applies clamping force, friction between disc and mating steel plate transfers engine torque to the gear set, delivering power for machine travel and loader working actions.

2.Power disengagement for shifting When hydraulic pressure releases, the disc separates from steel plates, cutting off power transmission temporarily. It enables smooth gear change without gear tooth impact or damage.

3.Shock & vibration absorption The paper friction material buffers impact loads during clutch engagement. It softens power shocks generated during loader bucket loading / sudden acceleration, protecting transmission gears and shafts.

4.Heat control with cooling grooves Grooves on disc surface allow transmission oil to flow through. Lubricating oil carries away friction heat, preventing overheating, burning and thermal deformation of friction lining.

5.Load holding When the clutch is fully engaged, the disc maintains stable friction coefficient to sustain heavy load, preventing clutch slipping under high working torque.

Compatible models

CHALLENGER 65 65C 65E 75 75C 75D 75E 85C 85D 85E 95E
INTEGRATED TOOLCARRIER IT62G IT62G II
LOAD HAUL DUMP R1300G II
WHEEL LOADER 950F II 950G 950G II 950H 960F 962G 962G II 962H 966C 966H 966K

More other friction disc parts fit for C A T machine

8E8310 DISC-THRUST

24H, 24M, 30/30, 35, 45, 55, 574, 583R, 583T, 589, 611, 615C, 824C, 834B, 836, 844, 844H, 844K, 854G, 854K, 980F, 980F II, 980G, 980G II, 988F II, 990, 990 II, 990H, 990K, 992C, 992D, 992G, 992K, 993K...

8E8316 DISC-THRUST

24H, 24M, 589, 65C, 65E, 75C, 75D, 75E, 824C, 824G, 824G II, 824H, 824K, 825G, 825G II, 825H, 825K, 826C, 826G, 826G II, 826H, 826K, 834G, 834H, 834K, 836, 836G, 836H, 836K, 844, 844H, 844K, 854G, 854...

3369318 DISC-FRICTION

777D, 777F, 777G, 789B, 789C, 789D, 793B, 793C, 793D, 834G, 834H, 834K, 836G, 836H, 844, 844H, 854G, 854K, 988G, 988H, 988K, 990, 990 II, 990H, 992G, 992K, 993K, 994D, 994F, 994H, CX48-P2300, SPF343C,...

8E8328 DISC-FRICTION

776C, 776D, 777B, 777D, 777F, 777G, 784B, 784C, 785, 785B, 785C, 789, 789B, 793, 793B, 793D, 834G, 836G, 988G, 988H, 990, 992G, 993K, 994, SPF343C, TH48-E80, TH55-E70

9T9452 DISC

235C, 5110B, 5230, 5230B, 651E, 657G, 793D, 963C, 993K

6E1688 DISC

229D, 231D, 5110B, 5130, 5130B, 5230, 5230B, 583T, 587R, 587T, 793C, 844, 844K, 854G, 854K, 990, 990 II, 990K, 992G, 992K, 993K

2339748 DISC-FRICTION

24H, 24M, 589, 824G, 824G II, 824H, 824K, 825G, 825G II, 825H, 825K, 826C, 826G, 826G II, 826H, 826K, 834B, 834G, 834H, 834K, 836, 836G, 836H, 836K, 844H, 844K, 854G, 854K, 980F, 980G, 980G II, 980H, ...

2368675 DISC-FRICTION

826C, 834G, 834H, 834K, 836G, 836H, 836K, 844, 844H, 844K, 854G, 854K, 980H, 980K, 986H, 988G, 988H, 988K, 990 II, 990H, 990K, 992G, 992K, 993K

8E0985 DISC AS-CLUTCH

844, 844H, 844K, 854G, 854K, 990, 990 II, 990H, 990K, 992C, 992D, 992G, 992K, 993K, 994, 994D, 994F, 994H, D10, D11N, D11R, D11T

6I8597 DISC-FRICTION

992G, 993K, 994

3249127 DISC-FRICTION

3641290 DISC

966H, 966K, 966M, 966M XE, 972H, 972K, 972M, 972M XE

1516399 DISC-FRICTION

966H, 972H

1412622 DISC-FRICTION

966G, 972G

3369315 DISC-FRICTION

854G, 854K, 992G, 992K, 994D, 994F, 994H

3341032 DISC-FRICTION

545, 545C, 814F, 814F II, 815F, 815F II, 816F, 816F II, 970F, R1600, R1600G, R1600H

4E7507 DISC-INNER

980F, 980F II

Catalog parts list

Pos.	Part No	Qty	Parts name	Comments
1	0L-1558	[1]	BOLT (1/2-20X3.25-IN)
2	5D-6141	[1]	RETAINER
3	2H-2665	[1]	SEAL-O-RING
4	9W-2147	[1]	YOKE AS
5	3S-9880	[1]	GUARD
6	9F-5088	[1]	SEAL-LIP TYPE
7	0S-1594	[6]	BOLT (3/8-16X1-IN)
8	9W-2799	[1]	COVER
9	1U-8846 B		SEALANT-GASKET
10	7T-9759	[1]	ROTOR-SENSOR (70 TEETH)
11	8E-3963	[1]	BEARING AS-ROLLER
12	006-7241	[1]	RING
13	3J-1907	[2]	SEAL-O-RING
14	2P-1294	[1]	PLUG-SEAL
15	105-4364 C	[1]	HOUSING-CLUTCH
16	1D-4569	[21]	BOLT (1/2-13X4.25-IN)
17	4J-1253	[1]	SEAL-O-RING
18	8M-4988	[1]	SEAL-O-RING
19	7T-6356	[1]	CARRIER AS
	2D-6642	[4]	BALL
20	7M-3916	[1]	BUSHING
21	3N-9423	[1]	SEAL-RING
22	3S-8109	[4]	PIN-SPRING
23	7T-3060	[4]	SHAFT-PLANETARY
24	7T-5273	[4]	GEAR-PLANETARY (29-TEETH)
	5P-8451	[4]	BEARING
25	8E-8303	[8]	DISC-THRUST
26	8E-8302	[1]	DISC-THRUST
27	7T-6357	[1]	DISC-THRUST
28	1P-9216	[1]	RING-SEAL
29	7T-5507	[1]	SEAL-RING
30	7T-5334	[1]	PISTON
31	8P-1656	[4]	PLATE-CLUTCH
32	6Y-2027	[4]	DISC-FRICTION
33	2L-3845 C	[5]	DOWEL
34	5J-9104	[5]	SPRING
35	1S-9989	[5]	DOWEL-REACTION
36	7T-5271	[1]	GEAR-RING (84-TEETH)
37	9S-4191	[2]	PLUG-O-RING
38	8E-6627	[1]	HOUSING-CLUTCH
39	1T-0765	[2]	BOLT (3/8-16X1-IN)
40	4J-1253	[1]	SEAL-O-RING
41	1M-3937	[1]	RING-METAL SEAL
42	9W-9404	[1]	CARRIER AS
	2D-6642	[2]	BALL
43	102-2176	[2]	RING-LOCK
44	3N-9423	[2]	SEAL-RING
45	4H-7925	[1]	RING-METAL SEAL
46	7G-5675	[2]	RING-SEAL
47	6P-7773	[2]	RING-SEAL
48	7T-1270	[4]	SHAFT-PLANETARY
49	8E-8303	[8]	DISC-THRUST
50	7T-1286	[4]	GEAR-PLANETARY (26-TEETH)
	5P-8451	[4]	BEARING
51	3S-8109	[8]	PIN-SPRING
52	6T-6987	[1]	PISTON-CLUTCH
53	7T-3343	[8]	PLATE-CLUTCH
54	7T-3456	[7]	DISC-FRICTION
55	5J-9104	[4]	SPRING
56	8E-6629	[1]	GEAR-RING (75 TEETH)
57	8E-6628	[1]	HOUSING-CLUTCH
58	9W-8491	[1]	CARRIER AS
	2D-6642	[2]	BALL
59	7T-1271	[4]	SHAFT-PLANETARY
60	8E-8298	[8]	DISC-THRUST
61	7T-1285	[4]	GEAR-PLANETARY (23-TEETH)
	7S-4534	[4]	BEARING-CAGED
62	7T-4569	[1]	GEAR-RING (90 TEETH)
63	8E-6630	[1]	PISTON-CLUTCH
64	5P-9862	[2]	RING
65	7T-1277	[2]	GEAR-SUN (42-TEETH)
66	3S-3440	[2]	WASHER-WAVE (68.1X80.8X0.5-MM THK)
67	9F-3823	[2]	RING-SEAL
68	7T-4529	[1]	CARRIER-RING
69	8E-4886	[1]	CARRIER-PLANETARY
70	2S-3567	[3]	BOLT-12 POINT HEAD (3/8-16X2.75-IN)
71	7T-1271	[3]	SHAFT-PLANETARY
72	8E-8298	[6]	DISC-THRUST
73	7T-1285	[3]	GEAR-PLANETARY (23-TEETH)
	7S-4534	[3]	BEARING-CAGED
74	3S-8109	[3]	PIN-SPRING
75	135-1993	[1]	PLATE-CENTER
76	7T-3343	[3]	PLATE-CLUTCH
77	7T-3456	[2]	DISC-FRICTION
78	7J-5938	[4]	SPRING
79	6T-6987	[1]	PISTON-CLUTCH
80	6P-7773	[1]	RING-SEAL
81	7G-5675	[1]	RING-SEAL
82	8E-5295	[1]	GEAR AS (90-TEETH)
	6V-4431	[9]	PLUG-CUP
83	7T-1279	[1]	CAGE-BEARING
84	1S-0579	[1]	BALL BEARING
85	7T-1283	[1]	PLATE-RETAINER
86	7T-5272	[1]	SHAFT-CENTER
87	5V-9266	[4]	ROD
88	7T-4883	[1]	SHAFT AS
	7T-4251	[1]	BUSHING
89	8E-4887	[1]	HOUSING-CLUTCH
90	5P-8245	[8]	WASHER-HARD (13.5X25.5X3-MM THK)
91	8T-1121	[6]	BOLT (1/2-13X8.75-IN)
92	2M-8868	[1]	RACE-BEARING OUTER
93	2A-1531	[2]	BOLT (1/2-13X6.5-IN)
	B		USE AS REQUIRED
	C		CHANGE FROM PREVIOUS TYPE
	R		REMFG PART MAY BE AVAILABLE

7T-3456 7T3456 Clutch Disc Wheel Loader Spare Parts Fit For 950H 960F 962G 966C

We could supply the following spare parts

1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.

2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.

3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.

4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.

5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.

6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.

Advantage

1. Offer Top quality & competitive products

2. Support 12-month warranty

3. 100% tested before shipping

4. Delivery in time

5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator

6. More than 15 years production and 11 years foreign trade experience

7. Professional QC team

8. Best sales team, 24 hours service

Packing and Shipping

Packing Details :

inner packing : plastic film for wrapping

external packing : wooden

Shipping :

within 3 days after received the payment , by air or by express or by sea on the basis of the

quantity and emergency circumstances.

1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,

2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.

3. By Sea: Delivery from the Huangpu port .
