- 7824-31-3600 7824313600 Throttle Motor KOMATSU Excavator Spare Parts For PC120 PC130
| Category |
Fuel Control |
| Name |
Throttle Motor |
| Parts No |
7824-31-3600 7824313600 |
| Machine Model |
PC120 PC130 PC150HD PC150NHD PC180 PC180L PC210 PC240 PC300 |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT EMS |
| Packing |
As request or standard packing
|
| 1. Engine Speed & Power Regulation (Primary Function) |
|
It receives electronic speed commands sent from the cabin throttle knob and working mode switch.
The built-in stepper motor drives the pull wire to swing the fuel injection pump governor lever, adjusting fuel supply volume precisely. It sets variable engine RPM from low idle (around 800rpm) to high working speed (max 2200rpm), matching power output for light-duty travel or heavy digging loads.
|
| |
| 2. Automatic Speed Stabilization & Load Compensation |
| Cooperates with engine speed sensor and excavator controller to realize closed-loop speed control: |
| When digging hard soil, hydraulic load surges → motor automatically increases throttle travel to supply more fuel, prevent engine speed drop, lugging or stall. |
| When load reduces (empty bucket moving), motor cuts fuel supply to avoid over-revving, eliminate abnormal noise and fuel waste. |
| |
| 3. Idle & Flameout Control |
| Startup: Automatically return to standard idle position after engine ignition to maintain stable low idle without manual adjustment. |
| Shutdown: After ignition key power-off, the motor pulls the governor to fuel cut-off position with short delay, completing safe engine flameout. No manual stop lever required. |
| |
| 4. Engine-Hydraulic Power Matching & Fuel Saving |
| It communicates with the main pump EPC solenoid valve. The controller adjusts motor travel based on target engine speed, balancing engine output power and hydraulic pump absorption power. It reduces hydraulic overflow loss, cuts fuel consumption and extends engine service life. |
BULLDOZERS D375A
EXCAVATORS PC120 PC130 PC150HD PC150NHD PC180 PC180L PC210 PC240 PC300 PC400 PW170 Komatsu
- More other motor parts fit for KOMATSU machine
| 21Y-60-21210 MOTOR ASS'Y |
| BZ210, PC128UU |
| |
| 706-7G-01041 MOTOR ASS'Y |
| PC200, PC210, PC220, PC230NHD, PC270, PC290 |
| |
| 7834-41-2001 MOTOR ASS'Y |
| BP500, BR380JG, BZ210, D275A, PC130, PC160, PC180, PC200, PC200LL, PC200SC, PC210, PC220, PC220LL, PC228, PC228US, PC230, PC230NHD, PC240, PC270, PC270LL, PC290, PC308, PW160, PW200, PW220 |
| |
| 7834-41-2000 MOTOR ASS'Y |
| BZ210, D275A, PC160, PC180, PC200, PC210, PC220, PC228, PC228US, PC230, PC230NHD, PC240, PC270, PC290, PC308, PW200, PW220 |
| |
| 7834-41-2002 MOTOR ASS'Y |
| BR300S, BR380JG, BZ210, D61EX, D61PX, PC130, PC160, PC200, PC220, PC228, PC228US, PC270, PC290, PW160, PW180, PW200, PW220 |
| |
| 21K-26-B7410 MOTOR SHAFT ASS'Y (K4) |
| PC160 |
| |
| 195-911-4660 MOTOR ASS'Y |
| D155C, D275A, D275AX, D355A, D375A, D475A, D475ASD, D85C, PC200, PC220, PC300, PC400 |
| |
| TZ979B200000FG MOTOR ASS'Y |
| BR100J, BR100JG, BR100RG, BZ200, BZ210, PC60, PC70, PC75US, PC78US |
| |
| YM12995377019 MOTOR, STARTER |
| WB140, WB140PS, WB150, WB150AWS, WB150PS, WB91R, WB93R, WB97R, WB97S |
| |
| YM12995377010 MOTOR, STARTER |
| 4D98E, WB140, WB140PS, WB150, WB150AWS, WB150PS, WB150WSC, WB91R, WB93R, WB97R, WB97S |
| |
| 706-8L-01010 MOTOR ASS'Y |
| PC550, PC600, PC650 |
| |
| YM172164-73311 MOTOR |
| PC40FR |
| |
| YM172164-73330 MOTOR |
| PC40FR |
| |
| 195-Z11-8530 MOTOR ASS'Y,R.H. |
| D155A, D275A, D375A, D61E, D65E |
| |
| 706-8J-01411 MOTOR, TRAVEL R.H |
| PC390, PC390LL, PC400, PC450, PC490 |
| |
| 890000023 MOTOR AND VALVE A. |
| 212 |
| |
| 871120116 MOTOR, ASSY. |
| SK04 |
| |
| YM172421-73300 MOTOR ASS'Y,DRIVING |
| PC20FR |
| |
| 37A-942-2010 MOTOR FAN |
| CK30, CK35, SK1020, SK1026, SK815, SK818, SK820 |
| |
| 706-73-01121 MOTOR ASS'Y |
| PC100, PC100L, PC120, PC130, PW130 |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
203-43-59513 |
[1] |
BRACKET Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 2 |
702-16-11490 |
[1] |
BEARING,NEEDLE Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 3 |
702-16-11510 |
[2] |
SEAL,OIL Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 4 |
01010-51040 |
[3] |
BOLT Komatsu |
0.288 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["0101081040"] |
|
| 5 |
01643-31032 |
[3] |
WASHER Komatsu |
0.054 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] |
|
| 6 |
7824-31-3600 |
[1] |
MOTOR ASS'Y,GOVERNOR Komatsu |
4.11 kg. |
| |
|
|
["SN: K20001-UP"] |
|
| 7 |
203-06-56351 |
[1] |
COVER Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 9 |
01011-51005 |
[2] |
BOLT Komatsu |
0.075 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["0101181005", "6121511250"] |
|
| 11 |
203-43-59522 |
[1] |
LEVER Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 12 |
01010-50830 |
[1] |
BOLT Komatsu |
0.017 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["0101080830", "6735511120", "0737200830", "1240145H1"] |
|
| 13 |
01602-20825 |
[1] |
WASHER,SPRING Komatsu |
0.004 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["0160200825", "0231011020", "6124613790"] |
|
| 14 |
21P-43-21140 |
[1] |
SPRING ASS'Y Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 15 |
20Y-43-18190 |
[1] |
YOKE Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 16 |
01580-10605 |
[1] |
NUT Komatsu |
0.01 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["21D0921430", "M018200600006", "801920103"] |
|
| 17 |
04205-10618 |
[2] |
PIN Komatsu |
0.002 kg. |
| |
|
|
["SN: K20001-UP"] |
|
| 18 |
04050-11612 |
[2] |
PIN,COTTER Komatsu |
0.001 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["0405001612", "2344318710"] |
|
| 19 |
203-43-K1251 |
[1] |
LEVER Komatsu China |
|
| |
|
|
["SN: K20500-UP"] analogs:["2034359541", "20343K1250"] |
|
| |
203-43-K1250 |
[1] |
LEVER Komatsu China |
|
| |
|
|
["SN: K20218-K20499"] analogs:["20343K1251", "2034359541"] |19. |
|
| |
203-43-59541 |
[1] |
LEVER Komatsu China |
|
| |
|
|
["SN: K20001-K20217"] analogs:["20343K1251", "20343K1250"] |19. |
|
| 20 |
01640-21426 |
[1] |
WASHER Komatsu China |
|
| |
|
|
["SN: K20001-UP"] analogs:["D40Q689", "M011611400006", "0164001426", "0164011426", "0164031426", "5654011420"] |
|
| 21 |
203-43-59550 |
[1] |
LEVER Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 22 |
04025-00432 |
[1] |
PIN,SPRING Komatsu |
0.002 kg. |
| |
|
|
["SN: K20001-UP"] |
|
| 23 |
04245-40619 |
[1] |
ROD Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 24 |
04250-40639 |
[1] |
END,ROD Komatsu |
0.026 kg. |
| |
|
|
["SN: K20001-UP"] |
|
| 25 |
21P-43-21130 |
[1] |
YOKE Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 27 |
01643-30623 |
[2] |
WASHER Komatsu |
0.002 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["0164370623"] |
|
| 28 |
01010-50625 |
[1] |
BOLT Komatsu |
0.007 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["0101030625", "0101080625"] |
|
| 29 |
203-43-59530 |
[1] |
PIN Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
| 30 |
04052-10633 |
[1] |
PIN,SNAP Komatsu |
0.42 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["0405200633"] |
|
| 31 |
08036-01014 |
[1] |
CLIP Komatsu |
0.013 kg. |
| |
|
|
["SN: K20001-UP"] |
|
| 32 |
01010-51016 |
[1] |
BOLT Komatsu |
0.06 kg. |
| |
|
|
["SN: K20001-UP"] analogs:["0101081016"] |
|
| 34 |
203-06-56570 |
[1] |
BAND Komatsu |
0.01 kg. |
| |
|
|
["SN: K20001-UP"] |
|
| 35 |
203-43-59150 |
[1] |
COVER Komatsu China |
|
| |
|
|
["SN: K20001-UP"] |
|
- We could supply the following spare parts
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
1. Offer Top quality & competitive products
2. Support 12-month warranty
3. 100% tested before shipping
4. Delivery in time
5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator
6. More than 15 years production and 11 years foreign trade experience
7. Professional QC team
8. Best sales team, 24 hours service
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
