- 702-16-01230 7021601230 Pilot Valve KOMATSU Excavator Spare Parts For PC120 PC130
| Name |
Pilot Valve |
| Parts No |
702-16-01230 |
| Machine Model |
PC110R PC120 PC120SC PC130 PC160 PC180 PC190 |
| Category |
Cab, Floor Mounts |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT EMS |
| Packing |
As request or standard packing |
| 1.Generate proportional pilot signal pressure |
| Converts operator foot‑pedal mechanical force into proportional low‑pressure pilot hydraulic signal. The output pilot pressure changes according to pedal stroke depth. |
| |
| 2.Control main control valve spool |
| Delivers pilot pressure signal to end caps of main distribution valve spools, shifts main spool to open main hydraulic oil circuit for travel function. |
| |
| 3.Forward‑reverse travel direction selection |
| One pedal achieves both forward and reverse travel commands; different output ports supply pilot pressure for forward or backward travel. |
| |
| 4.Proportional speed regulation |
| Deeper pedal depression → higher pilot pressure → larger opening of main valve spool → higher machine travel speed. Partial pedal stroke realizes slow travel. |
| |
| 5.Spring‑centered automatic return‑to‑neutral |
| When operator releases foot pedal, internal spring resets spool, cuts pilot pressure output, main valve spool returns neutral, machine stops traveling. |
| |
| 6.Oil return circuit management |
| Unloading surplus pilot oil back to hydraulic tank, maintains stable pilot system pressure. |
BULLDOZERS D37EX D37PX D39EX D39PX D61EX D61EXI D61PX D61PXI D65E D65EX D65PX D65WX D85E D85ESS D85EX D85PX
CRAWLER CARRIERS CD60R
EXCAVATORS PC100 PC100L PC100N PC110R PC120 PC120SC PC130 PC160 PC180 PC190 PC200 PC200CA PC200LL PC200SC PC200Z PC20UU PC210 PC220 PC220LL PC228 PC228US PC228UU PC230 PC230NHD PC240 PC250 PC270 PC28UU PC290 PC300 PC300HD PC300LL PC300SC PC308 PC30MR PC30R PC30UU PC340 PC350 PC350HD PC350LL PC35MR PC35R PC360 PC380 PC38UU PC38UUM PC390 PC390LL PC400 PC400ST PC40MR PC40MRX PC40R PC450 PC45MR PC45MRX PC45R PC490 PC50UU PC50UUM PC60 PC600 PC650 PC70 PC700 PC75 PC750 PC750SE PC75R PC75UU PC800 PC95R PW110R PW128UU PW130 PW140 PW148 PW160 PW180 PW200 PW220 PW75 PW75R PW95R
MOBILE CRUSHERS AND RECYCLERS BR100R BR100RG
OTHER BA100 Komatsu
- More other valve parts fit for KOMATSU machine
| 702-21-08701 PILOT VALVE |
| PC300, PC350, PC360, PRESSURE, RAIN |
| |
| 702-16-01690 PILOT VALVE |
| PC400 |
| |
| 702-16-05020 PILOT VALVE |
| PC750, PC750SE, PC800, PC800SE |
| |
| 702-16-01680 PILOT VALVE,(SEE FIG. Y1670-01A0) |
| PC1100, PC1100SE, PC1100SP |
| |
| 702-16-01681 PILOT VALVE |
| PC1100, PC1100SE, PC1100SP, PC800, PC800SE |
| |
| 702-16-01112 PILOT VALVE |
| D20A, D20AG, D20P, D20PG, D20PL, D20PLL, D20Q, D20S, D21A, D21AG, D21P, D21PG, D21PL, D21Q, D21QG, D21S |
| |
| 702-21-08512 PILOT VALVE |
| PC138US, PC78MR, PC78US, PC88MR, WINDOW |
| |
| 702-16-03910 PILOT VALVE,(SEE FIG.Y1670-11A2) |
| AIR, HB205, HB215, PC130, PC160, PC200, PC270, PC300, PC350, PC400, PC450, PRESSURE, RAIN |
| |
| 702-16-04960 PILOT VALVE |
| PC400 |
| |
| 702-21-08730 PILOT VALVE |
| PC400, PC450 |
| |
| 702-16-01012 PILOT VALVE |
| D60P, D65E, D65EX, D65P, D65PX, D85E, D85ESS, DRP060 |
| |
| 22B-30-12230 PILOT |
| PC100, PC120, PC128US, PC128UU, PC130, PC138, PC138US, WINDOW |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
22U-54-25660 |
[1] |
Seal Komatsu |
0.02 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 2 |
20Y-43-41760 |
[1] |
Seat Komatsu |
0.48 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 3 |
01010-81025 |
[2] |
Bolt Komatsu |
0.36 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["0101051025", "0101651025", "801015109"] |
|
| 4 |
01643-31032 |
[2] |
Washer Komatsu |
0.054 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] |
|
| 6 |
20Y-62-25360 |
[1] |
Bracket Komatsu |
0.67 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 7 |
01010-D1035 |
[2] |
Bolt Komatsu |
0.033 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["801015556", "0101081035", "0101051035"] |
|
| 8 |
01643-71032 |
[2] |
Washer Komatsu |
0.054 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["0164331032", "802150510", "0164331030", "0164381032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002"] |
|
| 9 |
20Y-53-14220 |
[1] |
Pedal Komatsu |
1.58 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 10 |
01010-D1045 |
[2] |
Bolt Komatsu |
0.039 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["0101051045", "0101081045"] |
|
| 12 |
22U-54-25180 |
[1] |
Plate Komatsu China |
|
| |
|
|
["SN: 60001-UP"] analogs:["22U5425180XC"] |
|
| 13 |
01010-81020 |
[1] |
Bolt Komatsu |
0.161 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["801014093", "0101051020", "801015108"] |
|
| 15 |
207-43-81240 |
[1] |
Cap Komatsu |
0.57 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 16 |
20T-910-8660 |
[1] |
Nipple Komatsu China |
|
| |
|
|
["SN: 60001-UP"] |
|
| 17 |
07000-12011 |
[1] |
O-ring Komatsu |
0.001 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["YM24315000110", "0700002011"] |
|
| 18 |
20Y-62-52160 |
[2] |
Elbow Komatsu China |
|
| |
|
|
["SN: 60001-UP"] |
|
| 19 |
02896-11008 |
[2] |
O-ring Komatsu China |
0.12 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 21 |
20Y-62-43470 |
[1] |
Nipple Komatsu |
0.07 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 23 |
11Y-62-12140 |
[1] |
Nipple Komatsu |
0.042 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 26 |
207-62-75780 |
[1] |
Hose Komatsu China |
|
| |
|
|
["SN: 60001-UP"] |
|
| 27 |
207-62-75770 |
[1] |
Hose Komatsu China |
|
| |
|
|
["SN: 60001-UP"] |
|
| 28 |
208-62-72310 |
[1] |
Hose Komatsu OEM |
0.16 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 29 |
208-62-72650 |
[1] |
Hose Komatsu OEM |
0.21 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 30 |
20Y-62-22790 |
[2] |
Band, Red Komatsu |
0.001 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 31 |
20Y-62-22820 |
[2] |
Band, Blue Komatsu |
0.01 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 32 |
20Y-62-22840 |
[2] |
Band, Black Komatsu |
0.001 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 33 |
20Y-62-22860 |
[2] |
Band, Brown Komatsu |
0.001 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 34 |
08034-20519 |
[2] |
Band Komatsu |
0.001 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["2260611130", "885180010"] |
|
| 35 |
04435-51210 |
[1] |
Clip Komatsu |
0.02 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 36 |
195-33-11220 |
[1] |
Spacer Komatsu |
0.073 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 37 |
01010-81050 |
[1] |
Bolt Komatsu |
0.038 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["801015559", "0101051050"] |
|
| 39 |
01583-11408 |
[1] |
Nut Komatsu |
0.4 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["801713411"] |
|
| 40 |
206-06-61130 |
[2] |
Switch, Pressure Komatsu OEM |
0.04 kg. |
| |
|
|
["SN: 60001-UP"] analogs:["2060661330"] |
|
| 41 |
20Y-53-14130 |
[1] |
Bracket Komatsu China |
|
| |
|
|
["SN: 60001-UP"] |
|
| 43 |
01580-11008 |
[2] |
Nut Komatsu |
0.011 kg. |
| |
|
|
["SN: 60001-UP"] |
|
| 45 |
702-16-01230 |
[-1] |
Valve Assembly, PPC Komatsu |
0.76 kg. |
| |
|
|
["SN: UP"] |
|
- We could supply the following spare parts
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
1. Offer Top quality & competitive products
2. Support 12-month warranty
3. 100% tested before shipping
4. Delivery in time
5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator
6. More than 15 years production and 11 years foreign trade experience
7. Professional QC team
8. Best sales team, 24 hours service
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
