| Category |
Cylinder Head Parts |
| Name |
Arm |
| Parts No |
VOE16671284 16671284 |
| Machine Number |
BL60B BL61B BL70B BL71B DD105 EC120D EC140D SD75 SD75B |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT |
| Packing |
As request or standard packing |
| 1.Seal the rod-end chamber of the cylinder barrel |
| Closes the front opening of the cylinder tube to form a sealed rod-side hydraulic chamber, preventing high-pressure hydraulic oil from leaking outward from the gap between piston rod and cylinder barrel. It works together with piston seals to maintain pressure difference inside the cylinder. |
| |
| 2.Install & locate the complete rod sealing system |
| The head body processes mounting grooves for: |
| Rod main seal (prevents external oil leakage) |
| Wiper dust seal (blocks mud, sand, rock dust from entering the cylinder, protects rod surface & inner seals) |
| Buffer seal / wear ring (absorb shock and reduce friction) |
| O-ring between cylinder head and barrel (barrel end static seal) |
| |
| 3.Guide and support the piston rod |
| Integrated or embedded guide bushing inside the cylinder head provides radial support for the reciprocating piston rod. It bears lateral side loads generated during excavator arm digging, pulling and swinging, avoiding direct contact between rod and cylinder barrel and preventing rod bending and barrel scoring. |
| |
| 4.Withstand cyclic high hydraulic pressure & impact loads |
| During arm crowd / arm dump operations, the gland continuously bears alternating high system pressure (typical excavator main working pressure: 26–33 MPa) and frequent impact loads from excavation. High-strength forged alloy steel structure ensures structural integrity without deformation or cracking. |
| |
| 5.Assembly and maintenance interface |
| It is a detachable component. After removing the cylinder head, technicians can replace all rod-side seals without fully taking apart piston & barrel assembly, greatly simplifying cylinder overhaul. |
BL60B BL61B BL70B BL71B DD105 EC120D EC140D SD75 SD75B
- More other arm applied to heavey machine
| VOE14704063 Arm |
| EC140D |
| |
| VOE14704064 Arm |
| EC120D, EC140D |
| |
| VOE17456022 Arm rest |
| DD105 |
| |
| VOE14697453 Arm |
| EC140D |
| |
| VOE14707460 Arm |
| EC140D |
| |
| VOE14707455 Arm |
| EC140D |
| |
| VOE14707458 Arm |
| EC140D |
| |
| VOE14705100 Arm |
| EC140D |
| |
| VOE14707456 Arm |
| EC140D |
| |
| VOE12815429 Arm |
| DD105 |
| |
| VOE14707459 Arm |
| EC140D |
| |
| VOE14707454 Arm |
| EC120D, EC140D |
| |
| RM20297149 Arm |
| AGS 7.5, P7110, P7110B, P7170, P7170B |
| |
| VOE14555895 Arm rest |
| EC140C, EC140D, EC140E, EC160C, EC160D, EC160E, EC180C, EC180D, EC180E, EC210C, EC220D, EC220E, EC235C, EC235D, EC240C, EC250D, EC250E, EC290C, EC300D, EC300E, EC330C, EC340D, EC350D, EC350E, EC360C, ... |
| |
| VOE14555900 Arm rest |
| EC140C, EC140D, EC140E, EC160C, EC160D, EC160E, EC180C, EC180D, EC180E, EC210C, EC220D, EC220E, EC235C, EC235D, EC240C, EC250D, EC250E, EC290C, EC300D, EC300E, EC330C, EC340D, EC350D, EC350E, EC360C, ... |
| |
| VOE14350489 Arm |
| EC210C, EW160C |
| |
| RM43839760 Arm |
| OMNI 318 |
| |
| RM43839547 Arm |
| OMNI 318 |
| |
| PJ7450095 Arm with bushes |
| EC15, EC15B |
| |
| RM13294830 Arm |
| SD77DA |
| |
| RM21143979 Arm |
| AGS 7.5 |
| |
| RM21143987 Arm |
| AGS 7.5, P7110B, P7170B |
| |
| RM13295266 Arm |
| SD77DA |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
VOE22673424 |
[1] |
Cylinder head |
|
| 2 |
VOE16658959 |
[5] |
Cap |
|
| 3 |
VOE16658973 |
[1] |
Cap |
|
| 4 |
VOE16658765 |
[1] |
Plug |
|
| 5 |
VOE16672694 |
[4] |
Stud |
|
| 6 |
VOE16671280 |
[8] |
Valve |
|
| 7 |
VOE16671268 |
[8] |
Valve |
|
| 8 |
VOE16669834 |
[16] |
Guide |
|
| 9 |
VOE16670182 |
[16] |
Valve stem seal |
|
| 10 |
VOE16670202 |
[16] |
Valve spring |
|
| 11 |
VOE16669831 |
[16] |
Retainer |
|
| 12 |
VOE16668857 |
[32] |
Collet |
SET |
| 13 |
VOE16670206 |
[8] |
Shaft |
|
| 14 |
VOE16671284 |
[8] |
Arm |
|
| 15 |
VOE16670217 |
[8] |
Pad |
|
| 16 |
VOE16670111 |
[18] |
Bolt |
|
| 17 |
VOE16672165 |
[1] |
Joint |
|
| 18 |
VOE16671966 |
[1] |
Hook |
|
| 19 |
VOE16672554 |
[4] |
Bolt |
|
| 20 |
VOE22673434 |
[1] |
Gasket |
STD/2 NOTCH |
| 20 |
VOE22673444 |
[1] |
Gasket |
SUITABILITY/1 NOTCH |
| 20 |
VOE22673446 |
[1] |
Gasket |
SUITABILITY/NOT NOTCH |
| 21 |
VOE16672640 |
[1] |
Stud |
|
| 22 |
VOE22802706 |
[1] |
Hook |
|
| 23 |
VOE16660606 |
[1] |
Nut |
|
