- VOE22383378 22383378 Oil Level Sensor Excavator Spare Parts For EC240C EC250E EC290B
| Name |
Oil Level Sensor |
| Parts No |
VOE22383378 22383378 |
| Machine Model |
EC240C EC250D EC250E EC290B EC290C EC300D EC300E EC350D |
| Category |
Cable Harness,Engine |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT EMS |
| Packing |
As request or standard packing |
The working principle is to measure the oil level height through a float. When the oil level changes, the float will move up and down, and at the same time, it will change the resistance value of the resistor. Thus, an electrical signal related to the oil level height is generated. This signal is transmitted to the vehicle's control unit, and then the control unit converts the oil - level signal into the actual oil - level height value, and displays it on the instrument panel, so that the driver can know the oil - level status in real - time.
EXCAVATORS EC240B EC240C EC250D EC250E EC290B EC290C EC300D EC300E EC350D ECR305C FC2924C FC3329C PL3005D PL3005E Vo.lvo.
- More other level sensor parts fit for V O L V O machine
| VOE11170064 Level guard |
| EC140C, EC140D, EC160C, EC160D, EC180C, EC180D, EC200B, EC210B, EC210C, EC220D, EC235C, EC235D, EC240B, EC240C, EC250D, EC250E, EC290B, EC290C, EC300D, EC300E, EC350D, ECR145C, ECR145D, ECR235C, ECR23... |
| |
| VOE14539976 Level indicating pipe |
| EC135B, EC140B, EC160B, EC160C, EC180B, EC180C, EC210B, EC210C, EC240B, EC290B, EC330B, EC360B, EC460B, EW140C, EW140D, EW145B, EW160C, EW160D, EW160E, EW180C, EW180D, EW180E, EW210C, EW210D, EW230C, ... |
| |
| VOE11715539 Level Guard |
| EC130C, EC130C ÅKERMAN, EC150C, EC150C ÅKERMAN, EC280, EC340, EC390, EC450, EC450 ÅKERMAN, EC650, EC650 ÅKERMAN, EW130C, EW130C ÅKERMAN, EW150C, EW150C ÅKERMAN |
| |
| VOE22383381 Level sensor |
| EC160C, EC180C, EC200B, EC210B, EC210C, EC220D, EC220E, EC235C, EC235D, ECR235C, ECR235D, ECR235E, EW145B, EW160C, EW160D, EW160E, EW180C, EW180D, EW180E, EW205D, EW210C, EW210D, EW230C, EWR150E, FC21... |
| |
| VOE16863600 Level indicator |
| L60G, L60H, L70G, L70H, L90G, L90H |
| |
| VOE16863603 Level sight glass |
| L60G, L60H, L70G, L70H, L90G, L90H |
| |
| VOE14340349 Level indicating pipe |
| EC280, EC340, EC390 |
| |
| VOE15179079 Level indicator |
| L60G, L70G, L90G |
| |
| VOE16041821 Level sight glass |
| L60GZ, L90GZ |
| |
| VOE16887923 Level sight glass |
| A35G, A40G, A45G, A45G FS |
| |
| VOE12776810 Level sight glass |
| P4370B |
| |
| VOE16894060 Level sight glass |
| A25G, A30G |
| |
| VOE12804753 Level sensor |
| DD105 |
| |
| VOE12789251 Level gauge |
| P6870/5870/5770C ABG |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
VOE20893636 |
[1] |
Main Cable Harness |
ENG - 10785521 |
| 1 |
VOE21814758 |
[1] |
Wiring harness |
ENG 10785522 - |
| |
|
[1] |
CONNECTED TO: |
|
| |
|
[1] |
Connector |
|
| |
|
[1] |
Engine speed,camshaft |
SE2703 |
| |
|
[1] |
Coolant temperature |
SE2606 |
| |
|
[1] |
Charge-air temperature |
SE2507, SE2508 |
| |
|
[1] |
Fuel Regulator |
|
| |
|
[1] |
Fuel Nozzle |
MA2301-MA2306 |
| |
|
[1] |
Fuel pressure |
SE2301 |
| |
|
[1] |
Oil pressure sensor |
SE2203 |
| |
|
[1] |
Engine speed |
SE2701 |
| |
|
[1] |
Pressure Sensor |
SE2309 |
| |
|
[1] |
Level Sensor |
SE2205, SE2202 |
| |
|
[1] |
Starter Motor |
|
| 2 |
VOE20799892 |
[1] |
Bracket |
|
| 3 |
VOE20460347 |
[7] |
Clamping band |
|
| 4 |
VOE23002666 |
[1] |
Connector |
|
| 5 |
VOE20460055 |
[3] |
Screw |
|
| 6 |
VOE21377079 |
[1] |
Bracket |
|
| 7 |
VOE20450802 |
[2] |
Flange screw |
|
| 8 |
VOE21896711 |
[1] |
Retaining plate |
|
| 9 |
VOE20405672 |
[4] |
Screw |
|
| 10 |
VOE4881440 |
[REQ] |
Cable tie |
|
| 11 |
VOE20450683 |
[1] |
Adapter |
|
| 12 |
VOE13947628 |
[1] |
Plane gasket |
|
| 13 |
VOE21531072 |
[1] |
Temperature sensor |
SE2606 |
| 14 |
VOE20524936 |
[1] |
Pressure sensor |
SE2507, SE2508 |
| 15 |
VOE20450728 |
[1] |
Bolt |
|
| 16 |
VOE22435058 |
[1] |
Sensor |
SE2703 |
| 17 |
VOE20450694 |
[1] |
Screw |
|
| 18 |
VOE20450694 |
[1] |
Screw |
|
| 19 |
VOE20450707 |
[1] |
Tachometer |
SE2701 |
| 20 |
VOE20700252 |
[1] |
Bracket |
|
| 21 |
VOE20799862 |
[2] |
Bolt |
|
| 22 |
VOE983472 |
[2] |
Cable tie |
|
| 23 |
VOE21291011 |
[1] |
Pressure sensor |
SE2203 |
| 24 |
|
[1] |
Sensor |
SE2301 |
| 25 |
VOE4881440 |
[6] |
Cable tie |
|
| 26 |
VOE22383378 |
[1] |
Level Sensor |
SE2205, SE2202 |
| 27 |
VOE20828295 |
[1] |
Sealing ring |
|
| 28 |
VOE20450867 |
[2] |
Clamp |
|
| 29 |
VOE20405792 |
[3] |
Screw |
|
| 30 |
VOE20852241 |
[1] |
Bracket |
|
| 31 |
|
[1] |
Pressure Sensor |
SE2309 |
| 32 |
VOE21598195 |
[1] |
Guard plate |
|
| 33 |
VOE20715095 |
[1] |
Closure |
|
| 34 |
VOE60100000 |
[1] |
Electronic unit |
E-ECU |
| 35 |
VOE21071773 |
[4] |
Rubber element |
|
| 36 |
VOE20792329 |
[1] |
Clamping Band |
|
| 36 |
VOE20834570 |
[8] |
Retainer |
|
| 37 |
VOE21063356 |
[2] |
Retainer |
|
| 38 |
|
[1] |
Cable Clamp |
|
