560-5010 455-7608 563-5011 470-4012 Radiator Hose Excavator Spare Parts For C6.4 323DL

Large Image : 560-5010 455-7608 563-5011 470-4012 Radiator Hose Excavator Spare Parts For C6.4 323DL

Product Details:

Place of Origin:	China
Brand Name:	OEM
Model Number:	560-5010 455-7608 563-5011 470-4012

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	23 USD / pcs
Packaging Details:	Wooden box for heavy parts, paper carton for light parts
Delivery Time:	3-7 working days
Payment Terms:	T/T, D/P, D/A,Western Union, L/C, MoneyGram
Supply Ability:	100-2000

Contact Now

Detailed Product Description

Category:	Radiator & Hydraulic Oil Cooler	Machine Model:	323DL
Application:	Excavator	Product Name:	Radiator Hose
Part Number:	560-5010 455-7608 563-5011 470-4012	Packing:	Standard Export Carton

560-5010 455-7608 563-5011 470-4012 Radiator Hose Excavator Spare Parts For C6.4 323DL

Specification

Name	Radiator Hose
Parts No	560-5010 455-7608 563-5011 470-4012
Machine Model	323DL
Category	Radiator & Hydraulic Oil Cooler
Lead time	1-3 DAYS
Quality	Brand new, OEM quality
MOQ	1 PCS
Means of transport	By sea/air, DHL FEDEX UPS TNT EMS
Packing	As request or standard packing

Function & Core Role

Coolant Circulation:
Radiator hoses facilitate the flow of ethylene glycol-based coolant between the engine’s cylinder head (hot side) and the radiator (cooling side). This ensures heat generated during combustion is dissipated efficiently, preventing engine overheating .

Heat Transfer: Hot coolant from the engine flows through the upper hose (e.g., 560-5010) to the radiator, where it cools via ambient air. Cooled coolant returns to the engine via the lower hose (e.g., 455-7608) .

Pressure Regulation: Hoses are engineered to withstand positive pressure (up to 241 kPa / 35 psi) created by the cooling system’s pressure cap, ensuring coolant remains in liquid form at high temperatures .

System Protection:

Vibration Resistance: Reinforced materials (e.g., synthetic rubber with polyester or rayon braids) absorb engine vibrations, reducing wear and tear on connections.

Leak Prevention: Precision-molded ends and compatible clamps (e.g., worm-drive or Oetiker clamps) ensure secure seals at radiator and engine ports .

Compatible models

EXCAVATOR 320D 323DL C.ater.pillar.

More other hose parts fit for C A T machine

1663152 HOSE AS

314D CR, 314D LCR, 314E CR, 314E LCR, 320B, 320C, 320C FM, 320C L, 320D, 320D FM, 320D FM RR, 320D L, 320D2, 320D2 L, 321D LCR, 323D L, 323D LN, 323D SA, 323D2 L

7Y4399 HOSE AS

320B, 320C, 320C FM, 320D, 320D L, 320D LRR, 320D RR, 321C, 322B, 322C, 322C FM, 323D L, 325B, 325B L, 325C, 325C FM, 330C FM, 330C MH, 330D, 330D FM, 330D L, 330D LN, 330D MH, 336D, 336D L, 336D LN, ...

1241047 HOSE AS

320B, 320B U, 320C, 320C FM, 320C L, 320D, 320D FM, 320D GC, 320D L, 320D LN, 320D2, 320D2 GC, 320D2 L, 320E, 320E L, 320E LN, 323D L, 323D LN, 323D SA, 323D2 L, 323E L

1876058 HOSE AS

320B, 320C, 320D, 320D L, 320D LN, 320D LRR, 320D RR, 320D2, 320D2 L, 320E, 320E LN, 320E LRR, 320E RR, 321D LCR, 323D L, 323D LN, 323D SA, 323D2 L, 323E L

1797867 HOSE AS

320C, 320C FM, 320C L, 320D, 320D FM, 320D GC, 320D L, 323D L, 323D LN

5I8510 HOSE AS

320D, 320D L, 320D LN, 320D LRR, 320D RR, 320D2, 320D2 L, 321D LCR, 323D L, 323D LN, 323D SA, 323D2 L, 325C, 330B L, 330C L, 345C, 345C L, 345D, 345D L, 345D L VG, 349D, 349D L, 350

2459178 HOSE-RADIATOR

320D, 320D FM, 320D GC, 320D L, 323D L, 323D LN

2653585 HOSE

320D, 320D FM, 320D GC, 320D L, 320D LN, 323D L, 323D LN, 323D SA

2653586 HOSE

320D, 320D FM, 320D GC, 320D L, 323D L, 323D LN

2653591 HOSE

320D, 320D FM, 320D GC, 320D L, 320D LN, 323D L, 323D LN, 323D SA

2653599 HOSE

320D, 320D FM, 320D GC, 320D L, 320D LN, 323D L, 323D LN, 323D SA

5I4216 HOSE AS

320D, 320D L, 320D LRR, 320D RR, 320D2, 320D2 GC, 320D2 L, 321D LCR, 323D L, 323D2 L, 325, 325 L, 325 LN, 325B, 325B L, 325C, 325D, 325D L, 329D, 329D L, 329D LN, 329E, 329E L, 329E LN, 336D2

3109500 HOSE AS

320D, 320D FM, 320D GC, 320D L, 323D L, 323D LN

3109498 HOSE AS

320D, 320D FM, 320D GC, 320D L, 323D L, 323D LN

2941773 HOSE

320D, 320D FM, 320D GC, 320D L, 323D L, 323D LN

2724139 HOSE AS

324D L, 325D L, 330D L, 336E, 336E L, 345C, 345C L, 345D, 345D L, 345D L VG, 349D, 349D L

2661135 HOSE AS

324D L, 325D L, 330D L

2391425 HOSE AS

320D, 324D L, 325B L, 325C, 325D L, 329D

Catalog parts list

Pos.	Part No	Qty	Parts name	Comments
1	096-4035	[1]	CLIP
2	096-5819	[1]	TANK AS-COOLANT (RECOVERY)
	171-3369	[1]	CAP AS (COOLANT RECOVERY)
3	171-9077	[1]	BAND
4	305-7664	[1]	BRACKET AS
5	245-9191	[1]	PLATE AS
6	398-0782	[1]	GUARD AS-FAN
7	399-7534	[1]	LINER
8	453-0614 Y	[1]	RADIATOR & HYD OIL COOLER GP
9	455-7608	[1]	HOSE-RADIATOR (LOWER)
10	470-4012	[1]	HOSE-RADIATOR (UPPER)
11	178-6450	[4]	SPACER (17X35X30-MM THK)
12	3P-9847	[1]	CLIP
13	3S-2093	[5]	STRAP-CABLE
14	7I-2673	[1]	STRAP-CABLE
15	453-2838 M	[4]	BOLT (M16X2X70-MM)
16	7X-7729	[7]	WASHER (11X25X3-MM THK)
17	8T-4121	[5]	WASHER-HARD (11X21X2.5-MM THK)
18	8T-4136 M	[2]	BOLT (M10X1.5X25-MM)
19	8T-4137 M	[6]	BOLT (M10X1.5X20-MM)
20	8T-4139 M	[2]	BOLT (M12X1.75X30-MM)
21	8T-4191 M	[4]	BOLT (M10X1.5X16-MM)
22	8T-4200 M	[2]	BOLT (M8X1.25X16-MM)
23	8T-4223	[2]	WASHER-HARD (13.5X25.5X3-MM THK)
24	8T-4224	[2]	WASHER-HARD (8.8X16X2-MM THK)
25	8T-6703	[4]	CLAMP-HOSE
26	7Y-1976 E		HOSE-WATER (38-CM)
27	5P-9909 D		SEAL (0.14-M)
28	5P-5649 D		SEAL-BULK (0.65-M)
28A.	5P-5649 D		SEAL-BULK (0.06-M)
	D		ORDER BY THE METER
	E		ORDER BY THE CENTIMETER
	M		METRIC PART
	Y		SEPARATE ILLUSTRATION

560-5010 455-7608 563-5011 470-4012 Radiator Hose Excavator Spare Parts For C6.4 323DL 0

We could supply the following spare parts

1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.

2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.

3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.

4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.

5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.

6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.

Advantage

1. Offer Top quality & competitive products

2. Support 12-month warranty

3. 100% tested before shipping

4. Delivery in time

5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator

6. More than 15 years production and 11 years foreign trade experience

7. Professional QC team

8. Best sales team, 24 hours service

Packing and Shipping

Packing Details :

inner packing : plastic film for wrapping

external packing : wooden

Shipping :

within 3 days after received the payment , by air or by express or by sea on the basis of the

quantity and emergency circumstances.

1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,

2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.

3. By Sea: Delivery from the Huangpu port .
