- 705-11-38040 7051138040 Pump KOMATSU Wheel Dozer Spare Parts Fitting For WD600-3
| Name |
Pump |
| Parts No |
705-11-38040 7051138040 |
| Machine Model |
D50P D80A D80E D80P D85A D85E D85P D135A D155A |
| Category |
Engine(Hydraulic Pump) |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT EMS |
| Packing |
As request or standard packing |
It is a rotary pump that transports liquid or increases pressure by relying on the change and movement of the working volume formed between the pump cylinder and the meshing gears. It has the ability of self - priming, and its flow has nothing to do with the discharge pressure.
It is crucial for maintaining the hydraulic flow required for the normal operation of the loader, providing power support for the loader's working devices such as the boom, bucket, and steering system, enabling these components to move and operate normally.
WHEEL DOZERS WD600 Komatsu
- More other pump parts fit for KOMATSU machine
| 704-30-42140 PUMP ASS'Y,(SAM3-125) |
| WA600, WA700, WD600 |
| |
| 423-947-1110 PUMP ASS'Y,MOTOR |
| 538, 542, 545, AIR, BATTERY, D37EX, D37PX, D39EX, D39PX, FRONT, JV100WA, JV100WP, JV130WH, WA100, WA1200, WA150, WA150L, WA150PZ, WA180, WA200, WA200L, WA200PT, WA200PTL, WA200PZ, WA250, WA250L, WA250... |
| |
| 705-13-40540 PUMP ASSEMBLY (SAL100) |
| 568, WA600, WD600 |
| |
| 705-53-31020 PUMP ASS'Y,(SAL3-125+32) |
| WA600, WD600 |
| |
| 705-53-42000 PUMP ASSEMBLY |
| 568, WA600, WD600 |
| |
| 705-13-42240 PUMP ASSEMBLY (SAL125) |
| 568, WA600, WD600 |
| |
| 705-23-30610 PUMP ASS'Y,(SAL32) |
| WA600, WD600 |
| |
| 705-21-42050 PUMP ASS'Y,(SAL125) |
| WA600, WD600 |
| |
| 30D-13-11310 PUMP |
| FD60, FD70, FD80 |
| |
| 705-41-04130 PUMP ASS'Y (SBR9A) |
| PC10, PC10N |
| |
| 705-41-03140 PUMP ASS'Y (SBR9A) |
| PC10, PC10N |
| |
| 705-37-38010 PUMP ASSEMBLY (SAL(3)80) |
| HYDRAULIC, WA500 |
| |
| 705-22-36410 PUMP ASS'Y,(SAR(3)63) |
| WA150, WA150L |
| |
| 81820KF PUMP, TRACK DRIVE |
| 430FX, 430FXL, 445FXL, 450FXL |
| |
| 2902440-1518A PUMP;GEAR |
| SOLAR |
| |
| 70430-29110 PUMP ASSEMBLY |
| WA200, WA250, WA250L, WA250PT, WA300, WA320 |
| |
| 155 711 PUMP, DRUM DRIVE |
| KOMATSU |
| |
| 840225169 PUMP, ASSY. |
| WB98A |
| |
| 705-11-26040 PUMP ASS'Y,(SEE FIG.6001) |
| WA50 |
| |
| 26C-61-11301 PUMP ASS'Y,HYDRAULIC |
| CS210 |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
705-11-38040 |
[1] |
PUMP,(SAL80) Komatsu |
13.28 kg. |
| |
|
|
["SN: 50001-UP"] |$0. |
|
| 1. |
705-17-03012 |
[1] |
BRACKET ASS'Y Komatsu |
3.54 kg. |
| |
|
|
["SN: 50001-UP"] |
|
| 1 |
705-17-03352 |
[2] |
BUSHING,PLANE Komatsu China |
0.05 kg. |
| |
|
|
["SN: 50001-UP"] analogs:["7051703351"] |
|
| 2. |
705-17-38010 |
[1] |
CASE,GEAR Komatsu |
2.584 kg. |
| |
|
|
["SN: 50001-UP"] |
|
| 3. |
705-17-03121 |
[1] |
COVER ASS'Y Komatsu |
2.66 kg. |
| |
|
|
["SN: 50001-UP"] |
|
| 4. |
705-17-38411 |
[1] |
GEAR,DRIVE Komatsu |
1.78 kg. |
| |
|
|
["SN: 50001-UP"] |
|
| 5. |
705-17-38511 |
[1] |
GEAR,DRIVEN Komatsu |
1.171 kg. |
| |
|
|
["SN: 50001-UP"] |
|
| 6. |
705-17-03610 |
[2] |
PLATE,SIDE Komatsu OEM |
0.184 kg. |
| |
|
|
["SN: 50001-UP"] |
|
| 7. |
705-17-03443 |
[2] |
RING,BACK-UP Komatsu China |
0.05 kg. |
| |
|
|
["SN: 50001-UP"] analogs:["7051703440"] |
|
| 8. |
705-17-03473 |
[2] |
SEAL,RING Komatsu China |
0.05 kg. |
| |
|
|
["SN: 50001-UP"] analogs:["7051703470"] |
|
| 9. |
705-17-03381 |
[2] |
O-RING Komatsu China |
0.05 kg. |
| |
|
|
["SN: 50001-UP"] analogs:["7051703380"] |
|
| 10. |
04020-01228 |
[4] |
PIN,DOWEL Komatsu |
0.026 kg. |
| |
|
|
["SN: 50001-UP"] analogs:["21T3016190"] |
|
| 11. |
705-17-03760 |
[4] |
BOLT Komatsu |
0.245 kg. |
| |
|
|
["SN: 50001-UP"] analogs:["0125361625"] |
|
| 12. |
01643-51645 |
[4] |
WASHER Komatsu |
0.021 kg. |
| |
|
|
["SN: 50001-UP"] |
|
| 13. |
705-17-03870 |
[1] |
PLATE Komatsu |
0.02 kg. |
| |
|
|
["SN: 50001-UP"] |
|
| 14. |
705-17-03811 |
[1] |
SEAL,OIL Komatsu |
0.03 kg. |
| |
|
|
["SN: 50001-UP"] analogs:["7051703810"] |
|
| 15. |
04065-05220 |
[1] |
RING,SNAP Komatsu China |
0.009 kg. |
| |
|
|
["SN: 50001-UP"] analogs:["802250552"] |
|
