Product Details:
Payment & Shipping Terms:
|
| Category: | Engine Parts | Machine Model: | 324D 324D L 324D LN 325D |
|---|---|---|---|
| Application: | Excavator | Product Name: | Chassis Wiring Harness |
| Part Number: | 283-2932 2832932 | Packing: | Standard Export Carton |
| Name | Chassis Wiring Harness |
| Parts No | 283-2932 2832932 |
| Machine Model | 324D 324D L 324D LN 325D |
| Category | Engine Parts |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT EMS |
| Packing | As request or standard packing |
| 1982713 HARNESS AS-ENGINE |
| 120K, 12K, 140G, 140K, 140K 2, 140M, 160K, 324D, 324D FM, 324D FM LL, 324D L, 324D LN, 325D, 325D FM, 325D FM LL, 325D L, 325D MH, 328D LCR, 329D, 329D L, 329D LN, 525C, 535C, 545C, 573, 584, 815B, 95... |
| 2225917 HARNESS AS-ENGINE |
| 120K, 120K 2, 12K, 12M, 140G, 140K, 140K 2, 140M, 160K, 324D, 324D FM, 324D FM LL, 324D L, 324D LN, 325D, 325D FM, 325D FM LL, 325D L, 325D MH, 326D L, 328D LCR, 329D, 329D L, 329D LN, 525C, 535C, 545... |
| 3812499 HARNESS AS-WIRING |
| 120K, 120K 2, 12K, 140K, 140K 2, 160K, 324D, 324D FM, 324D L, 324D LN, 325D, 325D FM, 325D FM LL, 325D L, 325D MH, 326D L, 328D LCR, 329D, 329D L, 329D LN, 525C, 535C, 545C, 950H, 962H, AP-1055D, BG-2... |
| 3669313 HARNESS AS-SENSOR |
| 311D LRR, 311F LRR, 312D, 312D L, 312D2, 314D CR, 314D LCR, 315D L, 318D2 L, 319D L, 319D LN, 320D, 320D L, 320D LN, 320D LRR, 320D RR, 321D LCR, 323D L, 323D LN, 323D SA, 324D, 324D L, 324D LN, 325D,... |
| 2457821 HARNESS AS-HEATER & AIR COND |
| 320D L, 323D L, 324D, 324D L, 324D LN, 325D, 325D L, 325D MH, 326D L, 328D LCR, 329D, 329D L, 329D LN, 330D, 330D L, 330D LN, 330D MH, 336D, 336D L, 336D LN, 336D2, 336D2 L, 340D L, 340D2 L, 345C, 345... |
| 2192357 HARNESS AS-LIGHTING |
| 325C, 325D L, 330C, 330D L |
| 3247830 HARNESS AS-PANEL |
| 325D L, 330D L, 345C L, 365C L, 385C L |
| 2510616 HARNESS AS-VALVE |
| 325D, 325D L, 329D |
| 3247827 HARNESS AS-SOLENOID |
| 325D L, 330D L, 345C L |
| 2801281 HARNESS AS-LIGHTING |
| 325D L, 330D L, 345C L |
| 2797161 HARNESS AS-PUMP |
| 325D L, 345C L |
| 2874650 HARNESS AS-CHASSIS |
| 325D L, 330D L |
| 2677969 HARNESS AS-CHASSIS |
| 324D, 324D L, 324D LN, 325D, 325D L |
| 2860029 HARNESS AS-CAB |
| 323D L, 323D LN, 324D LN, 325D, 325D L, 330D, 330D L, 330D LN, 336D L, 345C, 345C L, 365C, 365C L, 385C, 385C L |
| Pos. | Part No | Qty | Parts name | Comments |
| 1 | 2G-8767 | [3] | WASHER (10.5X60X3-MM THK) | |
| 2 | 3S-2093 | [46] | STRAP-CABLE | |
| 3 | 263-9574 | [2] | BATTERY (12-VOLT, MAINTENANCE FREE) | |
| (EACH INCLUDES) | ||||
| 123-1373 | [6] | CAP AS-FILLER (7/8-9-THD) | ||
| 4 | 5I-8270 | [1] | COVER-BATTERY | |
| 5 | 6W-6005 | [1] | HOLD-DOWN-BATTERY | |
| 6 | 7I-2673 | [5] | STRAP-CABLE | |
| 7 | 7K-1181 C | [14] | STRAP-CABLE | |
| 8 | 7Y-5456 | [2] | GROMMET | |
| 9 | 087-4587 | [1] | GROMMET | |
| 10 | 111-4836 | [10] | CLIP | |
| 11 | 111-4837 | [13] | CLIP | |
| 12 | 111-4838 | [9] | CLIP | |
| 13 | 111-4839 | [9] | STRAP | |
| 14 | 116-0118 | [12] | CLIP | |
| 15 | 132-1805 | [1] | STRAP AS-GROUND | |
| 16 | 135-8572 | [2] | BOLT AS | |
| 17 | 135-8573 | [2] | BOLT AS | |
| 18 | 140-0860 | [1] | STRAP AS-GROUND | |
| 19 | 170-6929 | [1] | CABLE AS | |
| 5P-0761 E | CABLE (00-GA, RED)(31-CM) | |||
| 9G-0002 | [1] | COVER AS-TERMINAL (RED) | ||
| 9G-0005 | [1] | COVER AS-TERMINAL (BLACK) | ||
| (EACH COVER-TERMINAL INCLUDES ) | ||||
| 8L-8413 | [1] | STRAP-CABLE (WHITE) | ||
| 8C-5918 | [1] | TERMINAL AS-BATTERY (NEGATIVE) | ||
| 8T-9756 | [1] | TERMINAL AS-BATTERY (POSITIVE) | ||
| (EACH TERMINAL AS INCLUDES) | ||||
| 1M-6119 | [1] | BOLT (5/16-18X1.375-IN) | ||
| 1M-6120 | [1] | NUT (5/16-18-THD) | ||
| 20 | 170-9336 | [1] | BRACKET AS | |
| 21 | 231-1827 | [1] | CABLE AS | |
| 1S-7252 | [1] | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | ||
| 5P-0747 E | CABLE (00-GA, BLACK)(23-CM) | |||
| 9G-0003 | [1] | COVER AS-TERMINAL (BLACK)(BATTERY) | ||
| 8L-8413 | [1] | STRAP-CABLE (WHITE) | ||
| 9G-8909 | [1] | COVER-TERMINAL (BLACK)(DISCONNECT SWITCH) | ||
| 8T-9757 | [1] | TERMINAL AS-BATTERY (NEGATIVE) | ||
| 1M-6119 | [1] | BOLT (5/16-18X1.375-IN) | ||
| 1M-6120 | [1] | NUT (5/16-18-THD) | ||
| 22 | 234-1051 | [2] | BRACKET | |
| 23 | 238-2501 | [1] | KNOB | |
| 24 | 238-2528 | [1] | ROD | |
| 25 | 238-2529 | [1] | BRACKET AS | |
| 26 | 250-5072 | [1] | SHEET AS | |
| 250-5073 | [1] | INSULATION | ||
| 27 | 250-5075 | [1] | SHEET AS | |
| 250-5076 | [1] | INSULATION | ||
| 28 | 251-0451 | [1] | CABLE AS | |
| 1S-7251 | [1] | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | ||
| 5P-0761 E | CABLE (00-GA, RED)(288-CM) | |||
| 8N-0869 | [1] | COVER-TERMINAL (RED)(STARTING MOTOR) | ||
| 8N-1725 | [1] | COVER AS-TERMINAL (RED)(BATTERY) | ||
| 8L-8413 | [1] | STRAP-CABLE (WHITE) | ||
| 3S-6049 | [1] | TERMINAL AS-BATTERY (POSITIVE) | ||
| 1M-6119 | [1] | BOLT (5/16-18X1.375-IN) | ||
| 1M-6120 | [1] | NUT (5/16-18-THD) | ||
| 29 | 251-0464 | [1] | GROMMET | |
| 30 | 251-0467 | [1] | BRACKET AS | |
| 31 | 256-1705 | [1] | SHEET AS | |
| 256-1707 | [1] | INSULATION | ||
| 32 | 283-2932 C | [1] | HARNESS AS-CHASSIS | |
| 102-8802 | [4] | KIT-RECEPTACLE (2-PIN) | ||
| 102-8803 | [3] | KIT-RECEPTACLE (3-PIN) | ||
| 102-8804 | [1] | KIT-RECEPTACLE (4-PIN) | ||
| 102-8806 | [1] | KIT-RECEPTACLE (8-PIN) | ||
| (EACH RECEPTACLE KIT INCLUDES RECEPTACLE AS & WEDGE) | ||||
| 153-2620 | [1] | PLUG AS-CONNECTOR (54-PIN, BLACK) | ||
| 153-2630 | [1] | PLUG AS-CONNECTOR (54-PIN, BROWN) | ||
| 155-2260 | [3] | KIT-CONNECTING PLUG (3-PIN) | ||
| 155-2270 | [17] | KIT-CONNECTING PLUG (2-PIN) | ||
| 155-2271 | [1] | KIT-CONNECTING PLUG (4-PIN) | ||
| (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) | ||||
| 160-7689 | [1] | PLUG AS-CONNECTOR (70-PIN) | ||
| 163-6637 | [1] | RECEPTACLE AS-CONNECTOR (54-PIN, BLACK) | ||
| 174-3016 | [2] | PLUG AS-CONNECTOR (3-PIN) | ||
| 230-4009 | [2] | PLUG AS-CONNECTOR (12-PIN) | ||
| 230-4011 | [7] | PLUG AS-CONNECTOR (2-PIN) | ||
| 230-4013 | [2] | PLUG AS-CONNECTOR (3-PIN) | ||
| 230-5010 | [2] | PLUG AS-CONNECTOR (6-PIN) | ||
| 231-2295 | [2] | PLUG AS-CONNECTOR (8-PIN) | ||
| 243-4505 | [6] | RECEPTACLE AS-CONNECTOR (2-PIN) | ||
| 243-4506 | [2] | RECEPTACLE AS-CONNECTOR (3-PIN) | ||
| 243-4508 | [2] | RECEPTACLE AS-CONNECTOR (6-PIN) | ||
| 243-4509 | [2] | RECEPTACLE AS-CONNECTOR (8-PIN) | ||
| 3S-2093 | [19] | STRAP-CABLE | ||
| 8T-8827 | [2] | BOOT (RED) | ||
| 103-2529 E | HOSE (75-CM) | |||
| 119-3662 E | TUBE-HEAT SHRINK (10.85-MM DIA)(33-CM) | |||
| 125-7874 E | TUBE-HEAT SHRINK (5.72-MM DIA)(75-CM) | |||
| 125-7875 E | TUBE-HEAT SHRINK (7.44-MM DIA)(40-CM) | |||
| 243-4510 | [2] | RECEPTACLE AS-CONNECTOR (12-PIN) | ||
| 33 | 093-2065 | [1] | GROMMET | |
| 34 | 132-5789 | [1] | CLIP (LADDER) | |
| 35 | 4I-7889 | [2] | SPACER (11X25X45-MM THK) | |
| 36 | 4K-8864 | [3] | CLIP (LOOP) | |
| 37 | 4P-7428 | [1] | CLIP (LADDER) | |
| 38 | 4P-7581 | [1] | CLIP (LADDER) | |
| 39 | 5C-7261 M | [1] | NUT (M8X1.25-THD) | |
| 40 | 5C-7883 M | [4] | BOLT-SOCKET HEAD (M6X1X16-MM) | |
| 41 | 5P-4116 | [2] | WASHER-HARD (8.8X20.5X2-MM THK) | |
| 42 | 6G-2256 | [2] | CLAMP | |
| 43 | 6G-2263 | [5] | SPACER (10.5X19X28.5-MM THK) | |
| 44 | 6K-8178 | [1] | CLIP (LOOP) | |
| 45 | 7X-2621 M | [2] | BOLT (M10X1.5X12-MM) | |
| 46 | 7Y-8165 | [2] | GROMMET | |
| 47 | 8M-2770 | [1] | CLIP (LOOP) | |
| 48 | 8T-4121 | [54] | WASHER-HARD (11X21X2.5-MM THK) | |
| 49 | 8T-4133 M | [1] | NUT (M10X1.5-THD) | |
| 50 | 8T-4136 M | [5] | BOLT (M10X1.5X25-MM) | |
| 51 | 8T-4137 M | [31] | BOLT (M10X1.5X20-MM) | |
| 52 | 8T-4172 M | [1] | BOLT (M10X1.5X80-MM) | |
| 53 | 8T-4182 M | [2] | BOLT (M10X1.5X45-MM) | |
| 54 | 8T-4185 M | [2] | BOLT (M10X1.5X50-MM) | |
| 55 | 8T-4189 M | [1] | BOLT (M8X1.25X20-MM) | |
| 56 | 8T-4191 M | [8] | BOLT (M10X1.5X16-MM) | |
| 57 | 8T-4195 M | [2] | BOLT (M10X1.5X30-MM) | |
| 58 | 8T-4226 | [1] | WASHER-PLATED (10.5X45X3-MM THK) | |
| 59 | 8T-5005 M | [1] | BOLT (M10X1.5X70-MM) | |
| 60 | 8T-6466 M | [1] | BOLT (M10X1.5X60-MM) | |
| 61 | 8T-6869 M | [1] | BOLT (M8X1.25X60-MM) | |
| 62 | 8T-6912 M | [1] | BOLT (M8X1.25X50-MM) | |
| 63 | 9X-8256 | [4] | WASHER (6.6X12X2-MM THK) | |
| 64 | 091-9035 | [1] | SPACER (11X25X20-MM THK) | |
| C | CHANGE FROM PREVIOUS TYPE | |||
| E | ORDER BY THE CENTIMETER | |||
| M | METRIC PART |
