Product Details:
Payment & Shipping Terms:
|
| Category: | Excavator Swing Reduction Gear | Machine Model: | R160LC-9 R180LC-9 R210LC-9 |
|---|---|---|---|
| Parts No.: | XKAQ-00529 | Parts Name: | GEAR, RING |
| Warranty: | 3/6 Months | Package: | Standard Export Carton |
| High Light: | R210LC-9 Swing Reduction Gear Ring,XKAQ-00529 Swing Reduction Gear Ring |
||
| spare parts name | Ring gear |
| Equipment Model | HYUNDAI R160 R180 R210 R160W R180W |
| Parts Category | Excavator swing reduction gear |
| Spare parts Condition | Brand new, OEM quality |
| MOQ of order(PCS, SET) | 1 |
| Parts Availability | In stock |
| Delivery Lead time | 1-3 days |
3929027 GEAR-CRANKSHAFT
100D-7, 33HDLL, H70, H80, HDF35A-2, HDF50A, HL720-3C, HL730-7, HL7303C, HL730TM3C, HL730TM7, HL740-3, HL740-3ATM, HL740-7, HL740-7S, HL740-9B, HL740-9S, HL740-9SB, HL740TM-3, HL740TM-3A, HL740TM-7, HL...
3905427 GEAR-FLYWHEEL RING
100D-7, 110D-7A, 110D-7E, 110D-9, 180DE, 250D-9, 250DE, 33HDLL, 42HDLL, HL17C, HL720-3C, HL730-7, HL730-7A, HL730-9, HL730-9A, HL730-9S, HL730-9SB, HL7303C, HL730TM-9, HL730TM-9A, HL730TM3C, HL730TM7,...
4896380 GEAR-CAMSHAFT
HL760-7A, HL760-9, HL760-9SB, R200W7A, R210W-9, R210W9MH, R250LC7A
M230X-00671 GEAR ASSY
R160LC7, R160LC9S, R170W7, R170W9S, R180LC7, R180LC9S, R180W9S
4893389 GEAR-FUEL PUMP
R200W7A, R210LC7A, R210LC9, R210NLC7A, R210NLC9, R250LC7A
XKBH-01932 GEAR-OIL PUMP DRIV
R210LC7H, R210LC9BH
XKBH-02183 GEAR SET
R210LC7H, R210LC9BH
XKBH-02185 GEAR
R210LC7H, R210LC9BH
39Q5-12110 GEAR-RING
HX160L, R160LC9, R160LC9A, R160LC9S, R160W9A, R170W9, R180LC9, R180LC9A, R180LC9S, R180W9A, R180W9S
39Q5-12270 GEAR-PLANETARY 1
HX160L, R160LC9, R160LC9A, R160LC9S, R160W9A, R170W9, R180LC9, R180LC9A, R180LC9S, R180W9A, R180W9S
39Q5-12320 GEAR-SUN 1
HX160L, R160LC9, R160LC9A, R160LC9S, R160W9A, R170W9, R180LC9, R180LC9A, R180LC9S, R180W9A, R180W9S
ZGAQ-04882 GEAR-RING
R160W9A, R170W9, R180W9A, R180W9S
XKAQ-00755 GEAR-SUN 2
HX160L, HX180L, R160LC9, R160LC9A, R160LC9S, R160W9A, R170W9, R170W9S, R180LC9, R180LC9A, R180LC9S, R180W9A, R180W9S, R210LC9, R210LC9BC, R210LC9BH, R210NLC9, R210W-9, R210W9A, R210W9AMH, R210W9MH, R2...
M230X-00671 GEAR ASSY
R160LC7, R160LC9S, R170W7, R170W9S, R180LC7, R180LC9S, R180W9S
32A35-12101 GEAR-OIL PUMP
R160LC7, R160LC9S, R170W7, R170W9S, R180LC7, R180LC9S, R180W9S
32A23-12401 GEAR-INJECTION PUMP
R160LC7, R160LC9S, R170W7, R170W9S, R180LC7, R180LC9S, R180W9S
32A23-01100 GEAR-CAMSHAFT
R160LC7, R160LC9S, R170W7, R170W9S, R180LC7, R180LC9S, R180W9S, R95W3
32A21-00900 GEAR-RING
R160LC7, R160LC9S, R170W7, R170W9S, R180LC7, R180LC9S, R180W9S, R95W3
32A23-00301 GEAR-CRANKSHAFT
R160LC7, R160LC9S, R
Pos.Part NoQtyParts nameComments
N*. @ [1] SWING MOTOR ASSY SEE 4100
*-2. 31Q6-10140 [1] SWING REDUCTION GEAR
*-2. 31Q6-10141 [1] SWING REDUCTION GEAR
*-2. 31Q6-10141AR [1] SWING REDUCTION GEAR
1. XKAQ-00771 [1] CASING
1. XKAQ-00962 [1] CASING
2. XKAQ-00403 [1] SHAFT-DRIVE
2. XKAQ-00780 [1] SHAFT-DRIVE
3. XKAQ-00018 [1] SPACER
4. XKAQ-00026 [1] BEARING-ROLLER
5. XKAQ-00032 [1] SEAL-OIL
6. XKAQ-00029 [1] BEARING-ROLLER
6. XKAQ-00647 [1] BEARING-ROLLER
6. XKAQ-00961 [1] BEARING-ROLLER
7. XKAQ-00404 [1] PLATE-THRUST
8. XKAQ-00753 [1] CARRIER ASSY 2 NOT SHOWN
9. XKAQ-00075 [1] CARRIER 2
10. XKAQ-00023 [3] GEAR-PLANET 2
11. XKAQ-00643 [3] PIN ASSY 2 NOT SHOWN
12. XKAQ-00070 [3] PIN 2 INLC 13
N13. XKAQ-00291 [1] BUSHING 2
14. XKAQ-00071 [6] WASHER-THRUST
15. XKAQ-00048 [3] PIN-SPRING
16. XKAQ-00755 [1] GEAR-SUN 2
17. XKAQ-00754 [1] CARRIER ASSY 1 NOT SHOWN
18. XKAQ-00531 [1] CARRIER 1
19. XKAQ-00025 [3] GEAR-PLANET 1
20. XKAQ-00532 [3] PIN 1
21. XKAQ-00030 [3] CAGE-NEEDLE
22. XKAQ-00057 [3] PLATE-SIDE 1
23. XKAQ-00040 [3] PLATE-SIDE 2
24. XKAQ-00041 [3] RING-STOP
25. XKAQ-00010 [1] GEAR-SUN 1
26. XKAQ-00534 [1] PLATE-SIDE 3
27. XKAQ-00529 [1] GEAR-RING
27. XKAQ-00779 [1] GEAR-RING
28. XKAQ-00977 [1] GEAR-PINION
29. XKAQ-00074 [1] RING-STOP
30. XKAQ-00072 [2] PIN-KNOCK
31. XKAQ-00065 [12] BOLT-SOCKET
32. XKAQ-00031 [1] PLATE-COVER
33. XKAQ-00064 [8] BOLT-HEX
34. XKAQ-00043 [1] PLATE-LOCK
35. XKAQ-00042 [2] BOLT-HEX
36. XKAQ-00292 [1] WASHER-LOCK
37. XKAQ-00049 [1] PLUG
38. XKAQ-00066 [2] PLUG
*-1. @ [1] SWING MOTOR UNIT SEE 4100
N. @ [AR] NOT SUPPLIED PARTS
Engine parts are designed precisely to work in engine system to meet the prime product requirements for machine performance, reliability, durability, operating costs and productivity.
1. Warranty Period: 3 Months' warranty from the date of arrival. Longer period of 6 months' warranty could be offered with higher price level.
2. Warranty type: replacement of the parts that have quality problem.
3. Warranty is not valid for below s
* Cutomer give wrong information about the order
* Force Majeure
* Wrong installation and operation
* Rust because of wrong stock & maintenance
* Strong carton or wooden box for gear components. Wooden box for gearbox assembly
* Delivery methods: By Sea, By air to local internation airport, By express like DHL TNT FEDEX
