300426-00049A 300426-00049B Doosan DX225 DX300 DX420 Excavator Monitor Panel Guage

• 300426-00049A 300426-00049B Doosan DX225 DX300 DX420 Excavator Monitor Panel Guage



• Specifications



Product name	guage panel
Part number	300426-00049A 300426-00049B
Model	DX300 DX225 DX340 DX420
Applied excavator	Doosan
Category group	Excavator Electric Parts
MOQ	1 PCS
Warranty	6 months
Payment term	T/T, Western Union, MoneyGram
Delivery time	1-3 days after receiving the payment
Packing	As request or standard packing
Means of transport	By sea/air, DHL







• Application



EXCAVATOR DOOSANDX140W DX170W DX210W DX140 DX180 DX225 DX255 DX300 DX340 DX380 DX350 DX420 DX520





• Parts Diagram



Key	Part No	Description	Qty	Serial No
-	300619-00673A	ELECTRIC ASSY;CABIN,ROPS	-	10003~10050
-	300619-00673B	ELECTRIC ASSY;CABIN,ROPS	-	10051~10114
-	300619-00673C	ELECTRIC ASSY;CABIN,ROPS	-	10115~10152
-	300619-00673G	ELECTRIC ASSY,CABIN;ROPS	-	10153~10158
-	300619-00673M	ELECTRIC ASSY;CABIN,ROPS	-	10159~10168
-	300619-00673N	ELECTRIC ASSY;CABIN,ROPS	-	10169~
2	DS0025056	BOLT	4
3	547-00023	SENSOR	1
4	D913109	NUT	4
5	K1053326	RELAY	5
6	S3450833	BOLT	4
7	S5100203	WASHER	6
8	2516-1116	BUZZER	1
9	S3450943	SCREW	2
10	S5102303	. WASHER	12
11	S3450983	SCREW	6	10003~10152
11	S3450983	SCREW	4	10153~
12	S5100003	WASHER	4
13	S3450343	SCREW	4
14	549-00090A	SWITCH,TOGGLE	1
15	K1001702A	SWITCH;TOGGLE	1
16	K1004427	PLATE,NAME	1
17	K1004425	PLATE;NAME	1
18	K1004426	PLATE,NAME	1
19	300611-00271A	CONTROLLER,WIPER	1	10153~
19	300611-00271	CONTROLLER;WIPER MOTOR	1	10007~10152
19	543-00106	CONTROLLER;WIPER	1	10003~10006
20	300612-00001A	CONVERTER,DC	1	10003~10152
20	300612-00001B	CONVERTER,DC	1	10153~
21	2543-9015	CONTROLLER;STARTER	1
22	S3450953	SCREW	4
23	310207-00708	HARNESS	1
24	S3450863	SCREW	2
25	545-00011	RESISTOR,AUXILIARY	1
26C	2527-1018	FUSE,BLADE 20A	4
26D	2527-1025	FUSE,BLADE 30A	2
26B	2527-1017	FUSE,BLADE 15A	6
26A	2527-1016	FUSE,BLADE 10A	16
26	310207-00616E	HARNESS,CABIN;ROPS	1	10159~
26	310207-00616B	HARNESS,CABIN;ROPS	1	10153~10158
26	310207-00616A	HARNESS,CABIN;ROPS	1	10003~10152
27	310207-00617	HARNESS,JOINT;ROPS(FRONT)	1
28	124-00208D4	CLIP	4	10159~
28	124-00208D4	CLIP	5	10003~10158
29	124-00208D2	CLAMP	2	10003~10158
29	124-00208D2	CLAMP	1	10159~
30	124-00208D3	CLIP	3	10159~
30	124-00208D3	CLIP	5	10003~10158
31	124-00208D5	CLIP	1	10159~
31	124-00208D5	CLIP	3	10003~10158
32	124-00208D6	CLIP	3
33	K1001029	BOLT	11	10003~10158
33	K1001029	BOLT	5	10159~
35	S3450603	SCREW M4X0.7X16	4
36	2121-1305	NUT	6
37	124-00208D7	CLIP	1
38	S5102103	WASHER	4
39	120106-00702	BOLT	2	10159~
39	S0508653	BOLT	2	10003~10158
40	S5102503	. WASHER	2	10003~10158
41	S5010513	WASHER	2	10003~10158
42	K1052850D28	PLATE,NAME;RELAY	1	10003~10158
42	950209-05930	PLATE,NAME;RELAY	1	10159~
43	190-01192D26	PLATE,NAME	1
44	2120-2166D53	. SCREW	3
46	2120-2166D52	. BOLT	2
47	301202-00042	RELAY	2
48	S3450973	SCREW M6X1.0X16	2	10153~
49	120402-00439	CLIP	5	10159~
50	120106-00596	BOLT	5	10159~
101	300611-00056A	CONTROLLER,EPOS	1	10003~10146
101	300611-00056B	CONTROLLER,EPOS	1	10147~10152
101	300611-00056E	CONTROLLER,EPOS	1	10159~
101-1	970306-00112	EPOS SOFTWARE	1	10153~
101	300611-00056C	CONTROLLER,EPOS	1	10153~10158
201	300426-00049B	PANEL,GAUGE;7 INCH	1	10115~10152
201	300426-00204	PANEL ASSY,GAUGE;7INCH UNIFIED(ROPS)	1	10153~
201	300426-00049A	PANEL,GAUGE;7INCH	1	10003~10114
201-1	970304-00001	GAUGE SOFTWARE	1	10153~
